Build
| Frame |
Ari Nebo Peak Full Suspension, 140mm travel. UDH derailleur hanger. Hanger Standard:Â UDH Colors:Â White Gold; Dune Red |
|---|---|
| Fork |
DVO Diamond D1, 29, 150mm travel, Boost 15×110 , 44mm offset, tapered steerer – Grey Travel:Â 150mm |
| Shock |
DVO Topaz Gen 3, 210×55, Custom Tuned Travel:Â 140mm |
| Headset |
Cane Creek 40 Series ZS Tapered ZS56 | ZS56/40 |
| Stem |
Ari Charger CNC 35 stem |
| Handlebar |
Ari Team 35mm bar-customized sizing through 23-Point Custom Setup |
| Saddle |
Ergon SM10 |
| Seatpost |
TranzX JD-YSI05J w/ Travel Adj. Dropper- customized sizing through 23-Point Custom Setup Type:Â Dropper |
| Pedals |
Available Separately |
Groupset
| Rear Derailleur |
Shimano SLX, SGS, 12-Speed |
|---|---|
| Front Derailleur |
N/A |
| Crank |
Praxis EC-6 Etor Spline 160mm |
| Shifters |
Shimano SLX Trigger 12-Speed |
| Cassette |
Shimano CS-M7100-12, 10-51t, 12-Speed |
| Chain |
Shimano SLX 12-Speed |
| Brakes |
TRP Slate Evo, HD-M807, TRP 2.3mm 180/180 F/R rotors Type:Â Hydraulic Disc |
Wheels
| Rims |
DT Swiss M 1900 Spline, 28 hole, Disc, Tubeless Ready |
|---|---|
| Spokes |
DT Champion Straightpull, black, with DT Swiss Squorx Prohead aluminium nipple |
| Front Hub |
F: DT Swiss 370, Sealed Bearing Disc, 110x15mm thru axle, 28 hole, 6 bolt; R: DT Swiss 370 Ratchet LN 18 Sealed Bearing Disc, 148x12mm thru axle, 28 hole, 6 bolt, MicroSpline |
| Rear Hub |
F: DT Swiss 370, Sealed Bearing Disc, 110x15mm thru axle, 28 hole, 6 bolt; R: DT Swiss 370 Ratchet LN 18 Sealed Bearing Disc, 148x12mm thru axle, 28 hole, 6 bolt, MicroSpline |
| Tires |
F: Maxxis Dissector 29×2.4, EXO+, 3C, TR Protection, Tubeless Ready. R: Maxxis Dissector 29×2.4, DoubleDown, 3C, MaxxTerra, TR Protection, Tubeless Ready |
Electric Components
| Motor |
Fazua Ride 60, 60Nm |
|---|---|
| Battery |
Fazua Energy 430Wh Fixed |
