Build
| Frame | Ari Wire Peak 2.0 Full Suspension, 145mm travel. UDH derailleur hanger. Hanger Standard: UDH Colors: Maroon Flame; Desert Silk |
|---|---|
| Fork | Rockshox Recon Silver RL, 29, 150mm travel, Boost 15×110 , 42mm offset, tapered steerer – Black Travel: 150mm Spring Type: Air |
| Shock | X-Fusion 02 Pro RL, 210×55, Custom Tuned Travel: 145mm |
| Headset | FSA Orbit 1.5 ZS No.57E, internal sealed cartridge bearing, tapered, with 10mm lower cup |
| Stem | Ari 35 stem |
| Handlebar | Ari Team 35, width 780/800mm, 25mm rise, 9 back sweep, 5 Up sweep, bar-customized sizing through 23-Point Custom Setup |
| Saddle | Selle Italia X3 Boost 148 |
| Seatpost | X-Fusion Manic- customized sizing through 23-Point Custom Setup Type: Dropper |
| Pedals | Available Separately |
Groupset
| Rear Derailleur | SRAM SX Eagle, 12-Speed |
|---|---|
| Front Derailleur | N/A |
| Crank | Shimano FC-E8000, 160mm |
| Shifters | SRAM SX Eagle Single Click Trigger 12-Speed |
| Cassette | SRAM PG-1210, 11-50t, 12-Speed |
| Chain | SRAM SX, 12-Speed |
| Brakes | TRP Slate Evo, HD-M807, TRP 2.3mm 203/203 F/R rotors Type: Hydraulic Disc |
Wheels
| Rims | WTB ST i30, 32 hole, Disc, Tubeless Ready |
|---|---|
| Spokes | 1.8mm (15g) black stainless, brass nipples |
| Front Hub | Front: Bear Pawls BMB 003 Sealed Bearing Disc Boost 110x15mm, Rear: Bear Pawls BEB 004 E-bike specific, 6 Sealed Bearings, Steel Axle, 6-bolts Disc, Boost 148x12mm, HG |
| Rear Hub | Front: Bear Pawls BMB 003 Sealed Bearing Disc Boost 110x15mm, Rear: Bear Pawls BEB 004 E-bike specific, 6 Sealed Bearings, Steel Axle, 6-bolts Disc, Boost 148x12mm, HG |
| Tires | Front: Maxxis Minion DHF 29X2.5 WT Exo Tubeless Ready 60 TPI, Rear: Maxxis Dissector 29X2.4 Exo Tubeless Ready |
Electric Components
| Motor | Shimano E7000 w/ Ari custom motor tune |
|---|---|
| Battery | Darfon 36V, 635Wh, Group A for E7000/EP8 |
