Build
Frame |
28″, ultra lite AL-6061 tubing, PowerTube battery, 120 mm rear travel BB Standard:Â Bosch, Press Fit Color:Â Matt Dark Brown |
---|---|
Fork |
Suntour Mobie 35 Air, LOR DS, 130 mm, 15×110 mm axle Travel:Â 130mm Spring Type:Â Air |
Shock |
Rock Shox Deluxe Select Plus RT Air, length x stroke 185×55, hardware: 45x8mm Travel:Â 120mm |
Bottom Bracket |
Bosch, Isis |
Headset |
Acros, A-Headset, semi-integrated, 1.5″, with integrated cable routing, with block lock |
Stem |
Satori Python, adjustable |
Handlebar |
BGM Pro, riserbar, backsweep: 15, rise: 5 mm |
Saddle |
Syncros Capilano Trekking Gel |
Seatpost |
Syncros Duncan, dropper post, 120 mm travel, remote Type:Â Dropper |
Pedals |
Trekking alloy |
Grips |
BGM Comfort, Ergo, double density, clamp version |
Groupset
Rear Derailleur |
Shimano Deore XT Linkglide, RD-M8130, Shadow Plus |
---|---|
Crank |
FSA CK-320, 38t |
Shifters |
Shimano Deore XT Linkglide, SL-M8130, 1×11-speed, rapidfire plus-shifter |
Cassette |
Shimano Linkglide, CS-LG600-11, 11-50t |
Chain |
Shimano Linkglide, CN-LG500 |
Brakes |
Shimano Deore XT, BR-M8100, hydraulic disc brake Type:Â Hydraulic Disc |
Brake Levers |
Shimano Deore XT, BL-T8100, hydraulic disc brake |
Wheels
Rims |
Alex EXR25, disc, eyelets, width: 25 mm |
---|---|
Spokes |
Sapim Leader |
Front Hub |
Shimano HB-MT400-B, centerlock, disc, 15×110 mm axle |
Rear Hub |
Shimano FH-MT400-B, centerlock, disc, 12×148 mm axle |
Tires |
Front: Schwalbe Hurricane, Addix, reflective stripe, 57-622 Tube: Schwalbe AV19, Rear: Schwalbe Hurricane, Addix, reflective stripe, 57-622 Tube: Schwalbe AV19 |
Disc Rotors |
Shimano SM-RT54, 180 mm |
Electric Components
Motor |
Bosch Performance Line CX, Gen. 4, BES3, 250 W, 36 V, max. 25 km/h |
---|---|
Battery |
Bosch PowerTube, 36 V Li Ion, 750 Wh |
Display |
Bosch LED Remote with Kiox 300 display |
Charger |
Bosch Standard Charger, 4A |
Accessories
Lights |
Front: B&M IQ-XS, 80 Lux, LED Rear: B&M Toplight Line brex, LED, with brake light |
---|---|
Fenders |
Curana Apollo, with stainless stays |
Racks |
Racktime / BGM E-Adventure carrier, SnapIt 2.0 System |
