Build
Frame |
28″, super lite AL-6061 tubing, BES III, PowerTube battery BB Standard:Â Bosch, Press Fit Color:Â Matt Black |
---|---|
Fork |
Suntour Mobie 25 Air, RLR DS, 100 mm, 15×100 mm axle Travel:Â 100mm Spring Type:Â Air |
Bottom Bracket |
Bosch, Isis |
Headset |
Acros, A-Headset, semi-integrated, 1.5″, with integrated cable routing |
Stem |
BGM E-Bike, adjustable, for Kiox integration |
Handlebar |
BGM Pro, riserbar, backsweep: 15, rise: 5 mm |
Saddle |
Syncros Capilano Trekking Gel |
Seatpost |
BGM Pro Type:Â Rigid |
Pedals |
Marwi SP-890 matt Sandblock |
Grips |
BGM Comfort, Ergo, double density, clamp version |
Groupset
Rear Derailleur |
Shimano Deore XT Linkglide, RD-M8130, Shadow Plus |
---|---|
Crank |
FSA CK-745, 38t |
Shifters |
Shimano Deore XT Linkglide, SL-M8130, 1×11-speed, rapidfire plus-shifter |
Cassette |
Shimano Linkglide, CS-LG600-11, 11-50t |
Chain |
Shimano Linkglide, CN-LG500 |
Brakes |
Shimano BR-MT420, hydraulic disc brake, 4-piston Type:Â Hydraulic Disc |
Brake Levers |
Shimano BL-MT402, hydraulic disc brake |
Wheels
Rims |
Ryde Rival 23 disc, eyelets |
---|---|
Spokes |
Sapim Leader |
Front Hub |
Shimano HB-MT400, centerlock, disc, 15×100 mm axle |
Rear Hub |
Shimano FH-UR600, centerlock, disc, quick release |
Tires |
Front: Schwalbe Marathon E-Plus, Smart Dual Guard, reflective stripe, 55-622 Tube: Schwalbe AV19, Rear: Schwalbe Marathon E-Plus, Smart Dual Guard, reflective stripe, 55-622 Tube: Schwalbe AV19 |
Disc Rotors |
Shimano SM-RT30, 180 mm |
Electric Components
Motor |
Bosch Performance Line CX, Gen. 4, BES3, 250 W, 36 V, max. 25 km/h |
---|---|
Battery |
Bosch PowerTube, 36 V Li Ion, 750 Wh |
Display |
Bosch LED Remote with Kiox 300 display |
Charger |
Bosch Standard Charger, 4A |
Accessories
Lights |
Front: B&M IQ-XS, 80 Lux, LED Rear: B&M Toplight Line brex, LED, with brake light |
---|---|
Fenders |
Racktime Alumee |
Racks |
Racktime / BGM Trekking Pro, Snapit 2.0 System, integrated fender mount |
