Build
Frame |
28″, super lite AL-6061 tubing, PowerTube battery BB Standard:Â Bosch, Press Fit |
---|---|
Fork |
Suntour Mobie 34 Air, 100 mm, 15×110 mm axle Travel:Â 100mm Spring Type:Â Air |
Bottom Bracket |
Bosch, Isis |
Headset |
Acros, A-Headset, semi-integrated, tapered, with integrated cable routing |
Stem |
Satori Python, adjustable |
Handlebar |
Syncros 3.0, riserbar, backsweep: 15, rise: 12 mm |
Saddle |
Syncros Capilano Trekking |
Seatpost |
BGM Pro Type:Â Rigid |
Pedals |
Marwi SP-823 |
Grips |
Syncros Urban, Ergo, double density, lock-on |
Groupset
Crank |
FSA CK-320, 170 mm, belt, 46t |
---|---|
Shifters |
Shimano Nexus, SL-C7000, 5-speed, revo-shifter |
Cassette |
Gates CDX, 32t |
Chain |
Gates CDX Carbon Drive Belt, Center-Track |
Brakes |
Shimano BR-MT420, hydraulic disc brake, 4-piston Type:Â Hydraulic Disc |
Brake Levers |
Shimano BL-MT402, hydraulic disc brake |
Wheels
Rims |
Cross X18, disc, eyelets, width: 30 mm |
---|---|
Spokes |
stainless, black |
Front Hub |
Shimano HB-TC500-B, centerlock, disc, 15×110 mm axle |
Rear Hub |
Shimano Nexus, SG-C7000-5, freehub, centerlock, disc |
Tires |
Front: Schwalbe Smart Sam, Performance, Addix, reflective stripe, 57-622 Tube: Schwalbe AV19B Light, Rear: Schwalbe Smart Sam, Performance, Addix, reflective stripe, 57-622 Tube: Schwalbe AV19B Light |
Disc Rotors |
Shimano SM-RT30, 180 mm |
Electric Components
Motor |
Bosch Smart System, Performance Line CX (BDU384Y), 250 W, 36 V, max. 25 km/h |
---|---|
Battery |
Bosch PowerTube, 36 V Li Ion, 600 Wh |
Display |
Bosch Intuvia 100 with LED Remote |
Charger |
Bosch Standard Charger, 4A |
Accessories
Lights |
Front: 100 Lux, LED Rear: Axa Juno, LED, with brake light function |
---|---|
Fenders |
Curana Orbit, with stainless stays |
Racks |
Racktime / BGM Trekking Pro, Snapit 2.0 System |
