Build
| Frame |
28″, ultra lite AL-6061 tubing, PowerTube battery, 130 mm travel BB Standard:Â Bosch, Press Fit |
|---|---|
| Fork |
X-Fusion MIG 34 Boost, 130 mm, 15×110 mm axle Travel:Â 130mm |
| Shock |
X-Fusion O2 Pro RLX, Trunnion, compression-, rebound. Adj. 130 mm Travel:Â 130mm |
| Bottom Bracket |
Bosch, Isis |
| Headset |
Acros, A-Headset, semi-integrated, tapered, with integrated cable routing |
| Stem |
Satori Python, adjustable |
| Handlebar |
BGM Pro, riserbar, backsweep: 15, rise: 5 mm |
| Saddle |
Syncros Tofino 2.5 |
| Seatpost |
BGM Pro Type:Â Rigid |
| Pedals |
Trekking alloy |
| Grips |
BGM Comfort, Ergo, double density, lock-on |
Groupset
| Rear Derailleur |
Shimano Cues, RD-U6000, Shadow Plus |
|---|---|
| Crank |
FSA CK-220, 170 mm, 38t |
| Shifters |
Shimano Cues, SL-U6000, 1×10-speed, rapidfire plus-shifter |
| Cassette |
Shimano Cues, CS-LG400-10, 11-48t |
| Chain |
Shimano Linkglide, CN-LG500 |
| Brakes |
Front: Shimano BR-MT420, hydraulic disc brake, 4-piston Rear: Shimano BR-MT410, hydraulic disc brake Type:Â Hydraulic Disc |
| Brake Levers |
Shimano BL-M4100, hydraulic disc brake |
Wheels
| Rims |
Syncros MD30, disc, eyelets, tubeless ready |
|---|---|
| Spokes |
Sapim Leader |
| Front Hub |
Shimano HB-TC500-B, centerlock, disc, 15×110 mm axle |
| Rear Hub |
Shimano FH-TC500, centerlock, disc, 12×148 mm axle |
| Tires |
Front: Schwalbe Johnny Watts LR, Performance, Addix, reflective stripe, 60-622 Tube: Schwalbe SV19, Rear: Schwalbe Johnny Watts LR, Performance, Addix, reflective stripe, 60-622 Tube: Schwalbe SV19 |
| Disc Rotors |
Front: Shimano SM-RT30, 203 mm Rear: Shimano SM-RT30, 180 mm |
Electric Components
| Motor |
Bosch Smart System, Performance Line CX, 250 W, 36 V, max. 25 km/h |
|---|---|
| Battery |
Bosch PowerTube, 36 V Li Ion, 800 Wh |
| Display |
Bosch Intuvia 100 / Mini Remote / TT System Controller |
| Charger |
Bosch Standard Charger, 4A |
Accessories
| Lights |
Front: Litemove SEC 150, 150 Lux, LED Rear: B&M Toplight Line Sensor, LED, with brake light function |
|---|---|
| Fenders |
Curana Orbit, with stainless stays |
| Racks |
Racktime / BGM, Snapit 2.0 System |
