Build
Frame |
28″, super lite AL-6061 tubing, PowerTube battery BB Standard:Â Bosch, Press Fit |
---|---|
Fork |
Suntour NVX 30 DS NLO, 75 mm Travel:Â 75mm Spring Type:Â Coil |
Bottom Bracket |
Bosch, Isis |
Headset |
Acros, A-Headset, semi-integrated, tapered, with integrated cable routing |
Stem |
Satori Python, adjustable |
Handlebar |
Satori Seagull, backsweep: 40, rise: 40 mm |
Saddle |
Syncros Capilano City |
Seatpost |
BGM Pro Type:Â Rigid |
Pedals |
Marwi SP-827, sandblock |
Grips |
Syncros Urban, Ergo, double density, lock-on |
Groupset
Crank |
FSA CK-320, 170 mm, belt, 46t |
---|---|
Shifters |
Shimano Nexus, SL-C7000, 5-speed, revo-shifter |
Cassette |
Gates CDX, 32t |
Chain |
Gates CDX Carbon Drive Belt, Center-Track |
Brakes |
Shimano BR-MT200, hydraulic disc brake Type:Â Hydraulic Disc |
Brake Levers |
Shimano BL-MT200, hydraulic disc brake |
Wheels
Rims |
BGM Pro X17, disc, eyelets |
---|---|
Spokes |
stainless, black |
Front Hub |
Shimano HB-MT200, centerlock, disc, quick release |
Rear Hub |
Shimano Nexus, SG-C7000-5, freehub, centerlock, disc |
Tires |
Front: Schwalbe Energizer Plus Tour, Performance, Greenguard, reflective stripe, 55-622 Tube: Schwalbe AV19B Light, Rear: Schwalbe Energizer Plus Tour, Performance, Greenguard, reflective stripe, 55-622 Tube: Schwalbe AV19B Light |
Disc Rotors |
Shimano SM-RT10, 180 mm |
Electric Components
Motor |
Bosch Smart System, Performance Line CX, 250 W, 36 V, max. 25 km/h |
---|---|
Battery |
Bosch PowerTube, 36 V Li Ion, 600 Wh |
Display |
Bosch Intuvia 100 with LED Remote |
Charger |
Bosch Standard Charger, 4A |
Accessories
Lights |
Front: Trelock LS830, 80 Lux, LED Rear: Axa Juno, LED, with brake light function |
---|---|
Fenders |
Curana Orbit, with stainless stays |
Racks |
Racktime / BGM Trekking Pro, Snapit 2.0 System |
