Build
Frame |
29″, ultra lite AL-6061 tubing, PowerTube battery, 120 mm rear travel BB Standard:Â Bosch, Press Fit Color:Â Shiny Petrol Blue |
---|---|
Fork |
X-Fusion E-Slide, 130 mm, 15×110 mm axle Travel:Â 130mm |
Shock |
Rock Shox Deluxe Select Plus Air, length x stroke 185×55, hardware: 45x8mm Travel:Â 120mm |
Bottom Bracket |
Bosch, Isis |
Headset |
Acros, A-Headset, semi-integrated, 1.5″, with integrated cable routing, with block lock |
Stem |
Satori Viper, 0 |
Handlebar |
Syncros Hixon 2.0, riserbar, rise: 12 mm, width: 780 mm |
Saddle |
Syncros Tofino 2.5 |
Seatpost |
Syncros Duncan 2.5, dropper post, 150 mm (frame size “S”: 125 mm), remote Type:Â Dropper |
Pedals |
none |
Grips |
Syncros E-MTB |
Groupset
Rear Derailleur |
Shimano Deore, RD-M6100, Shadow Plus |
---|---|
Crank |
FSA CK-320, 34t, 165 mm |
Shifters |
Shimano Deore, SL-M6100, 1×12-speed, rapidfire plus-shifter |
Cassette |
Shimano Deore, CS-M6100, 10-51t |
Chain |
KMC e12S |
Brakes |
Shimano BR-MT420, hydraulic disc brake, 4-piston Type:Â Hydraulic Disc |
Brake Levers |
Shimano BL-MT401, hydraulic disc brake |
Wheels
Rims |
Alex EXR30, disc, eyelets, width: 30 mm |
---|---|
Spokes |
Sapim Leader |
Front Hub |
Shimano HB-MT400-B, centerlock, disc, 15×110 mm axle |
Rear Hub |
Shimano FH-MT410-B, centerlock, disc, 12×148 mm axle |
Tires |
Front: Schwalbe Wicked Will Performance, folding, Addix Soft, 29×2.60″ Tube: Schwalbe SV19FB Light, Rear: Schwalbe Wicked Will Performance, folding, Addix Soft, 29×2.60″ Tube: Schwalbe SV19FB Light |
Disc Rotors |
Shimano SM-RT30, 203 mm |
Electric Components
Motor |
Bosch Performance Line CX, Gen. 4, BES3, 250 W, 36 V, max. 25 km/h |
---|---|
Battery |
Bosch PowerTube, 36 V Li Ion, 625 Wh |
Display |
Bosch LED Remote with Kiox 300 display |
Charger |
Bosch Standard Charger, 4A |
Accessories
Racks |
Racktime / BGM E-Adventure carrier, SnapIt 2.0 System |
---|
