Build
| Frame |
29/27.5″, ultra lite AL-6061 tubing, PowerTube battery, 140 mm rear travel BB Standard:Â Bosch, Press Fit Color:Â Matt Khaki Green |
|---|---|
| Fork |
X-Fusion Trace 36 RC, 150 mm, 15×110 mm axle Travel:Â 150mm Spring Type:Â Air |
| Shock |
Rock Shox Deluxe Select Plus RT Air, length x stroke 205×65, hardware: body bearing mount eyelet Travel:Â 140mm |
| Bottom Bracket |
Bosch, Isis |
| Headset |
Acros, A-Headset, semi-integrated, 1.5″, with integrated cable routing, with block lock |
| Stem |
Satori Viper, 0 |
| Handlebar |
Syncros Hixon 2.0, riserbar, rise: 12 mm, width: 780 mm |
| Saddle |
Syncros Tofino 2.5 |
| Seatpost |
Syncros Duncan 2.5, dropper post, 150 mm (frame size “S”: 125 mm), remote Type:Â Dropper |
| Pedals |
none |
| Grips |
Syncros E-MTB |
Groupset
| Rear Derailleur |
Shimano Deore, RD-M6100, Shadow Plus |
|---|---|
| Crank |
e*thirteen e*spec Plus crank / e*spec Base chainring, 34t, 165 mm |
| Shifters |
Shimano Deore, SL-M6100, 1×12-speed, rapidfire plus-shifter |
| Cassette |
Shimano Deore, CS-M6100, 10-51t |
| Chain |
KMC e12S |
| Brakes |
Shimano BR-MT420, hydraulic disc brake, 4-piston Type:Â Hydraulic Disc |
| Brake Levers |
Shimano BL-MT401, hydraulic disc brake |
Wheels
| Rims |
Alex EXR30, disc, eyelets, 29″ / Alex EXR30, disc, eyelets, 27.5″ |
|---|---|
| Spokes |
Sapim Leader |
| Front Hub |
Shimano HB-MT400-B, centerlock, disc, 15×110 mm axle |
| Rear Hub |
Shimano FH-MT410-B, centerlock, disc, 12×148 mm axle |
| Tires |
Front: Schwalbe Magic Mary Evo, folding, Addix Soft, 29×2.60″ Tube: Schwalbe SV19FB Light, Rear: Schwalbe Hans Dampf Evo, folding, Addix Soft, 27.5×2.60″ Tube: Schwalbe SV19FB Light |
| Disc Rotors |
Shimano SM-RT30, 203 mm |
Electric Components
| Motor |
Bosch Performance Line CX, Gen. 4, BES3, 250 W, 36 V, max. 25 km/h |
|---|---|
| Battery |
Bosch PowerTube, 36 V Li Ion, 625 Wh |
| Display |
Bosch LED Remote with Kiox 300 display |
| Charger |
Bosch Standard Charger, 4A |
