Build
Frame |
28″, lite investment casting, ultra lite AL-6061 tubing, CompactTube battery BB Standard:Â Bosch, Press Fit |
---|---|
Fork |
Suntour NRX32-E-Air LOR DS, 75 mm, 15×100 mm axle Travel:Â 75mm Spring Type:Â Air |
Bottom Bracket |
Bosch, Isis |
Headset |
Acros, A-Headset, semi-integrated, 1.5″, with integrated cable routing |
Stem |
Satori Rana, 20 |
Handlebar |
BGM Pro, riserbar, backsweep: 40, rise: 40 mm |
Saddle |
Syncros Capilano City |
Seatpost |
BGM Pro Type:Â Rigid |
Pedals |
Marwi SP-827, sandblock |
Grips |
Syncros Urban, Ergo, double density, lock-on |
Groupset
Crank |
FSA CK-220, 170 mm, belt, 52t |
---|---|
Shifters |
Enviolo, Automatic |
Cassette |
Gates CDC, 26t |
Chain |
Gates CDC Carbon Drive Belt, Center-Track |
Brakes |
Shimano BR-MT410, hydraulic disc brake Type:Â Hydraulic Disc |
Brake Levers |
Shimano BL-MT402, hydraulic disc brake |
Wheels
Rims |
BGM Pro X15, disc, eyelets |
---|---|
Spokes |
stainless, black |
Front Hub |
Shimano HB-TC500, centerlock, disc, 15×100 mm axle |
Rear Hub |
Enviolo City, 6-bolt, disc |
Tires |
Front: Schwalbe Marathon Efficiency, Performance, RaceGuard, reflective stripe, 55-622 Tube: Schwalbe SV19B Light, Rear: Schwalbe Marathon Efficiency, Performance, RaceGuard, reflective stripe, 55-622 Tube: Schwalbe SV19B Light |
Disc Rotors |
Shimano SM-RT30, 180 mm |
Electric Components
Motor |
Bosch Performance Line SX, 250 W, 36 V, max. 25 km/h |
---|---|
Battery |
Bosch CompactTube, 36 V Li Ion, 400 Wh |
Display |
Bosch Kiox 300 with LED Remote |
Charger |
Bosch Compact Charger, 2A |
Accessories
Lights |
Front: 100 Lux, LED Rear: Axa Juno, LED, with brake light function |
---|---|
Fenders |
Curana C-Lite, with stainless stays |
Racks |
Racktime / BGM E-Ville carrier, Snapit 2.0 System |
