Build
| Frame |
E-Bravo HPR, 3BS 6061 Hydroformed and aluminum parts with Technology PCP Precision Casting Process, Full internal cable system ICS2, Headset integrated OH2S 1-1/2″ – 1-1.8″, Post mount 180mm, 29×2.35″ maximum tyre, Thru axle Boost 12x148mm, UDH Standard, weight: 2700gr BB Standard:Â BSA, 73mm, Threaded Hanger Standard:Â UDH Color:Â Black-White Pearl-Blue Electro-Brillo |
|---|---|
| Fork |
RockShox 35 GOLD RL, Motion Control, 15x110mm Maxle Stealth, Tapered steerer, Rake 44mm, 35mm straight wall steel, Fast Black, 120mm travel, weight: 2277gr Travel:Â 120mm Spring Type:Â Air |
| Bottom Bracket |
BSA, 73mm, threaded |
| Handlebar |
Avanforce AF2 MTB, Aluminum 6061, 31,8mm, width 780mm, Backsweep 6, Upsweep 5, Rise 20mm, weight: 330gr |
| Saddle |
Essax Era, Steel rails, length: 250mm, width: 145mm, weight: 280gr |
| Seatpost |
Avanforce AF2, Aluminum 7075, 0 offset, 31,6 x 400mm, weight 205gr Type:Â Rigid |
Groupset
| Rear Derailleur |
SRAM NX Eagle, Aluminum cage, 12 Speed |
|---|---|
| Crank |
Bafang Aluminum Alloy Cranks, 165-170mm, 34T |
| Cassette |
SRAM PG 1210 Eagle, 11-50T |
| Chain |
SRAM SX Eagle A1, 118 links |
| Brakes |
SRAM DB8 Black 4 Piston Type:Â Hydraulic Disc |
Wheels
| Rims |
Mavic E-Crossride 29″, 15×110, Boost 12x148mm, TLR, HG11 Rear Hub, 6 Bolts, internal width: 30mm, weight: 2225gr |
|---|---|
| Tires |
Vittoria Barzo 29×2,35″, Tubeless ready, Graphene 2.0, 120 TPI, weight: 820gr |
Electric Components
| Motor |
BAFANG M-SERIES 510, 250W – 60Nm, Peak Power and Torque: 500W – 95 Nm, Q factor 177mm, weight: 3370gr |
|---|---|
| Battery |
PORTAPOWER 720Wh 36V 20Ah, Cells SAMSUNG INR21700-50E, 3960g |
| Display |
BAFANG DP C24.5 DISPLAY LCD, 15 features, USB port, Bluetooth comunication (DP C421), Bafang GO App |
| Charger |
Porta Power charger 220-240V 3A |
