Build
Frame |
Full-suspension BESV TCE Series frame, carbon front and rear triangle, SHIMANO E-BIKE SYSTEMS and internal battery compatible Color:Â Bright Desert Sands with Dark Desert Sands |
---|---|
Fork |
Fox 38 Ebike Performance Float, 38mm stanchions, Air damping, 1.1/8″-1.5″ tapered alloy steerer, travel 160mm Travel:Â 160mm Spring Type:Â Air |
Shock |
Fox Performance Float X, 205×60, air spring, 150mm rear wheel travel |
Bottom Bracket |
Shimano, integrated in motor |
Headset |
Acros, AZX-581, 1.5″ headset, angular contact bearings, integrated cable routing |
Stem |
E-MTB 3D Forged alloy stem, 35mm clamp, for internal cable routing |
Handlebar |
E-MTB reis bar, 6066 alloy, 15mm rise, sweep: 7 degree back, 35mm clamp |
Saddle |
Selle Italia Model-X Superflow eBike |
Seatpost |
Kind Shock LEV-SI dropper post with remote lever, travel: 175mm, 30.9mm diameter, 0mm offset Type:Â Dropper |
Pedals |
Wellgo, alloy body, ball bearings, with pins |
Grips |
Race Face Half-Nelson |
Groupset
Rear Derailleur |
Shimano SLX RD-M7100, 12 speed |
---|---|
Crank |
Shimano FC-EM600 for Shimano EP801, Shimano CRE80 34T chainring |
Shifters |
Shimano SLX SL-M7100, 12 speed |
Cassette |
Shimano Deore CS-M6100, 12 speed, 10-51T |
Chain |
KMC e12Turbo, with Quick-Link |
Brakes |
Shimano SLX M7120, 4-piston hydraulic disc, with 203mm front and rear rotors Type:Â Hydraulic Disc |
Brake Levers |
Shimano SLX M7100, 2 finger lever |
Wheels
Rims |
Race Face Aeffect-R, eMTB wheelset, front: 29″/ rear: 27.5+, Boost hubs spacing, Race Face multichamber alloy rims 32H |
---|---|
Tires |
29″x2.5″ |
Electric Components
Motor |
Shimano EP801 center-motor, 250W rated power, 85Nm of torque, 25km/h maximum assist |
---|---|
Battery |
720WH |
Display |
Shimano SC-EM800, center mounted, with LCD display, Bluetooth and ANT private connectivity, left hand switch |
