Build
| Frame | Full-suspension BESV TRS Series alloy frame, SHIMANO E-BIKE SYSTEMS and internal battery compatible Color: Forest Green with Night Black |
|---|---|
| Fork | Fox 36 Ebike Rhytm Float, 36mm stanchions, Air damping, 1.1/8″-1.5″ tapered alloy steerer, travel 160mm Travel: 160mm Spring Type: Air |
| Shock | Fox Performance Float DPS, 230×65, air spring, 160mm rear wheel travel |
| Bottom Bracket | Shimano, integrated in motor |
| Headset | Acros, AZX-581, 1.8″ headset, angular contact bearings, integrated cable routing |
| Stem | E-MTB 3D Forged alloy stem, 35mm clamp, for internal cable routing |
| Handlebar | E-MTB reis bar, 6066 alloy, 15mm rise, sweep: 7 degree back, 35mm clamp |
| Saddle | Selle Italia Model-X Superflow eBike |
| Seatpost | Kind Shock LEV-SI dropper post with remote lever, 30.9mm diameter, 0mm offset Type: Dropper |
| Pedals | Wellgo, alloy body, ball bearings |
| Grips | E-MTB gel grips with padding and BESV clamp |
Groupset
| Rear Derailleur | Shimano Deore XT RD-M8100, 12 speed |
|---|---|
| Crank | Samox for SHIMANO E-BIKE SYSTEMS, 34T chainring |
| Shifters | Shimano Deore SL-M6100, 12 speed |
| Cassette | Shimano Deore CS-M6100, 12 speed, 10-51T |
| Chain | KMC e12Turbo, with Quick-Link |
| Brakes | Shimano Deore M6120, 4-piston hydraulic disc, with 203mm front and rear rotors Type: Hydraulic Disc |
| Brake Levers | Shimano Deore M6100, 2 finger lever |
Wheels
| Rims | Formula CL-811 front hub, Formula CL-3248M rear hub, Boost hubs spacing, WTB STi30 29″ multichamber alloy rims 32H |
|---|---|
| Tires | 29″x2.6″ |
Electric Components
| Motor | Shimano EP801 center-motor, 250W rated power, 85Nm of torque, 25km/h maximum assist |
|---|---|
| Battery | 720Wh |
| Display | Shimano SC-EM800, center mounted, LCD display, Bluetooth and ANT private connectivity, left hand switch |
