Build
| Frame |
Full-suspension BESV TRS Series smooth welded alloy frame, SHIMANO E-BIKE SYSTEMS and internal battery compatible Color:Â Intense Red with Black Gloss |
|---|---|
| Fork |
Fox 36 E-bike Rhytm Float, 36mm stanchions, Air damping, 1 1/8″-1.5″ tapered alloy steerer, travel 160mm Travel:Â 160mm Spring Type:Â Air |
| Shock |
Fox Performance Float DPS, 230×65, air spring, 160mm rear wheel travel |
| Bottom Bracket |
Shimano, integrated in motor |
| Headset |
Acros, AZX-581, 1.8″ reduction to 1.5″ headset, angular contact bearings, integrated cable routing |
| Stem |
E-MTB 3D Forged alloy stem, 35mm clamp, for internal cable routing |
| Handlebar |
E-MTB rizer bar, 6066 alloy, 15mm rise, sweep: 7 back, 35mm clamp |
| Saddle |
Selle Italia Model-X Superflow Comfort+ |
| Seatpost |
Kind Shock LEV-SI dropper post with remote lever, 30.9mm diameter, 0mm offset Type:Â Dropper |
| Pedals |
Wellgo, alloy body, ball bearings |
| Grips |
E-MTB gel grips with padding and BESV clamp |
Groupset
| Rear Derailleur |
Shimano Deore XT RD-M8100, 12 speed |
|---|---|
| Crank |
Samox for SHIMANO E-BIKE SYSTEMS, 34T chainring |
| Shifters |
Shimano Deore SL-M6100, 12 speed |
| Cassette |
Shimano Deore CS-M6100, 12 speed, 10-51T |
| Chain |
KMC e12Turbo, with Quick-Link |
| Brakes |
Hydraulic Disc Type:Â Hydraulic Disc |
Wheels
| Rims |
Shimano HB-TC500-15-B front hub and HB-TC500-MS-B rear hub, Boost hubs spacing, WTB STi30 29″ multichamber alloy rims 32H |
|---|---|
| Tires |
29 x 2.6 |
Electric Components
| Motor |
Shimano EP801 (85Nm) |
|---|---|
| Battery |
800WH |
| Display |
Shimano SC-EN600, left hand mounted, with LCD display and Bluetooth connectivity |
