Build
Frame |
Full-suspension BESV TRS Series alloy frame, SHIMANO E-BIKE SYSTEMS and internal battery compatible Color:Â Metallic Titanium with Night Black |
---|---|
Fork |
SR Suntour Zeron35, 35mm stanchions, Lockout, Air damping, 1.1/8″-1.8″ tapered alloy steerer, travel 150mm Travel:Â 150mm Spring Type:Â Air |
Shock |
SR Suntour Edge LOR8, 230×65, air spring |
Bottom Bracket |
Shimano, integrated in motor |
Headset |
Acros, AZX-581, 1.8″ headset, angular contact bearings, integrated cable routing |
Stem |
E-MTB 3D Forged alloy stem, 35mm clamp, for internal cable routing |
Handlebar |
E-MTB reis bar, 6066 alloy, 15mm rise, sweep: 7 degree back, 35mm clamp |
Saddle |
Selle Italia X3 eBike |
Seatpost |
Kind Shock e10, 30.9mm diameter Type:Â Dropper |
Pedals |
Wellgo, alloy body, ball bearings |
Grips |
E-MTB gel grips with padding and BESV clamp |
Groupset
Rear Derailleur |
Shimano Deore XT RD-M8100, 12 speed |
---|---|
Crank |
Samox for SHIMANO E-BIKE SYSTEMS, 34T chainring with ring guard |
Shifters |
Shimano Deore SL-M6100, 12 speed |
Cassette |
Shimano Deore CS-M6100, 12 speed, 10-51T |
Chain |
KMC e12Turbo, with Quick-Link |
Brakes |
Shimano MT420, 4-piston hydraulic disc, with 203mm front and rear rotors Type:Â Hydraulic Disc |
Brake Levers |
Shimano MT4100, 2 finger lever |
Wheels
Rims |
Formula CL-811 front hub, Formula CL-3248M, Boost hubs spacing, WTB STi27 29″ multichamber alloy rims 32H |
---|---|
Tires |
57×622 |
Electric Components
Motor |
Shimano EP600 center-motor, 250W rated power, 85Nm of torque, 25km/h maximum assist |
---|---|
Battery |
720Wh |
Display |
Shimano SC-E5003, left hand mounted, with LCD display |
Accessories
Lights |
Front: Lezyne eBike Power E115, 6-12v, 115 lux, with reflector, Rear: Herrmans H-Cargo, 6-12v, with reflector |
---|---|
Fenders |
Alloy extruded fenders, front & rear 3/4 length, stainless steel hardware |
Racks |
Rear: Tubular aluminium carrier, with Snap-IT platform and spring clamp, H-Cargo rear light mount |
