Build
| Frame |
Hard-tail BESV TRX Series alloy frame, SHIMANO E-BIKE SYSTEMS and internal battery compatible Color:Â Trail Khaki with Night Black |
|---|---|
| Fork |
SR Suntour XCR34, 34mm stanchions, Lockout, Air damping, 1.1/8″-1.5″ tapered alloy steerer, travel man: 120mm lady: 100mm Travel:Â 120mm Spring Type:Â Air |
| Bottom Bracket |
Shimano, integrated in motor |
| Headset |
Acros, AZX-581, 1.5″ headset, angular contact bearings, integrated cable routing |
| Stem |
E-MTB 3D Forged alloy stem, 31.8mm clamp, for internal cable routing |
| Handlebar |
E-MTB reis bar, 6066 alloy, 4mm rise, sweep: 7 degree back, 31.8mm clamp |
| Saddle |
Selle Italia X3 eBike |
| Seatpost |
Promax SP-726, 31.6mm diameter Type:Â Rigid |
| Pedals |
Wellgo, alloy body, ball bearings |
| Grips |
E-MTB gel grips with padding and BESV clamp |
Groupset
| Rear Derailleur |
Shimano Deore RD-M6100, 12 speed |
|---|---|
| Crank |
Samox for SHIMANO E-BIKE SYSTEMS, 34T chainring |
| Shifters |
Shimano Deore SL-M6100, 12 speed |
| Cassette |
Shimano Deore CS-M6100, 12 speed, 10-51T |
| Chain |
KMC e12Turbo, with Quick-LinkT |
| Brakes |
Shimano MT420/MT410, 4/2-piston hydraulic disc, with 203mm front and 180mm rear rotors Type:Â Hydraulic Disc |
| Brake Levers |
Shimano MT4100, 2 finger lever |
Wheels
| Rims |
Formula CL-811 front hub, Formula CL-3248M rear hub, Boost hubs spacing, WTB STi27 29″ multichamber alloy rims 32H |
|---|---|
| Tires |
9″x2.4″ |
Electric Components
| Motor |
Shimano EP600 center-motor, 250W rated power, 85Nm of torque, 25km/h maximum assist |
|---|---|
| Battery |
720WH |
| Display |
Shimano SC-E5003, left hand mounted, with LCD display |
