Build
Frame |
E-Road Aria aero carbon, mechanical/electronic, BB-PressFit 86,5×41, head tube 1.4″-1.1/8″, integrated seat clamp, full carbon dropout, aero shape DT-ST, Disc brake flat mount, QR sytem, OLD 135mm sizes 47-50-53-55-57-59-61cm BB Standard:Â BB86/BB92, Press Fit Colors:Â 1a – Ck16 / Black Full Glossy; Pz – Summertime Dream / Black Full Glossy |
---|---|
Fork |
Full Carbon Aero Road 1.4″>1.1/8″ integrated head, Disc brake flat mount, thru axle 12×100 |
Bottom Bracket |
Shimano,SM-BB72-41B, PRESS FIT TYPE FOR ROAD, BEARING, INNER COVER |
Headset |
FSA Orbit C-33, NO.44E, 1-1/8 |
Stem |
Velomann, raise – 6, height 38mm, Oversize, 1 1/8″, size 90/100/110/120cm Ext: 90mm-48/50cm, 100mm-52/54cm, 110mm-56cm, 120mm-58cm |
Handlebar |
Velomann, Flat Top, alloy 6061 diam. 31,8mm, reach 80mm, drop 130mm Size: 400mm-44/53cm, 420mm-55/59cm, 440mm-61cm |
Saddle |
Velomann, carbon steel rail, 262×145 |
Seatpost |
Full Carbon Aero special dimension, special Clamp type with alloy head adjustable and reversible +/- 35mm; lenght: 300mm – 47/50cm; 350mm – 53/61 Type:Â Rigid |
Grips |
La Spirale Ribbon cork |
Groupset
Rear Derailleur |
Shimano, RD-R7150, 105,12-SPEED |
---|---|
Front Derailleur |
Shimano, FD-R7150, 105 |
Crank |
Shimano, FC-R7100, 105, 50-34T Crank Length: 47-50-53 – 170mm 55-57-59 – 172.5mm61L – 175mm |
Shifters |
Shimano DISC BRAKE SET, 105, ST-R7170 |
Chain |
Shimano, CN-M7100, HG 12-SPEED |
Brakes |
Shimano included in the shifter Type:Â Hydraulic Disc |
Wheels
Rims |
FSA Vision Trimax alloy disc with rear Mahle motor hub |
---|---|
Rear Hub |
FSA Vision Trimax alloy disc with rear Mahle motor hub |
Tires |
Vittoria Rubino Pro G2.0 graphene, 700 x 28c, 150TPI |
Disc Rotors |
Shimano, SM-RT86, S 160MM |
Electric Components
Motor |
Mahle X35 Plus 250W motor unit, iWOC One remote control, BLE and ANT+ compatible |
---|---|
Battery |
Mahle X35+ 250Wh |
