Build
| Frame |
e-Omnia C Type Step Thru chain drive ALU, size: SM, MD, LG (45-50-55), Ready to fix the chainguard, Post mount 180mm disc brake type, Ready to fix rear kyckstand, custom rearcarrier integrated in the frame, BatteryWall Bosch OmniaC, Set dropout IG 135mm I BB Standard:Â Bosch, Press Fit Color:Â Bk – Black Glossy |
|---|---|
| Fork |
SR SUNTOUR XCM34 BOOST LOR DS 29″ TRAVEL 100MM Travel:Â 100mm Spring Type:Â Coil |
| Bottom Bracket |
Included w/motor unit |
| Headset |
Fsa NO.55R/558 1.5″ |
| Stem |
Velomann 35,3D FORGED 0>90 L70MM |
| Handlebar |
Velomann AL6061, diam. 31.8mm, width 630mm, Rise 34mm, Backsweep 41 |
| Saddle |
Velomann A038UE0 Unisex, Rail Elastomer, black steel rail, 256×220 |
| Seatpost |
Velomann, lenght 350mm-15/17” and 400mm-19/21”, diam.31,6mm, 0mm seatback, AL2014 shaft Type:Â Rigid |
| Grips |
HERRMANS LUNA LOCK |
Groupset
| Crank |
FSA METROPOLIS ALLOY E-BIKE SPECIFIC, CRANK LENGTH 170MM, ISIS BB AXLE, W/GATES CARBON DRIVE CDX 39T |
|---|---|
| Shifters |
Shimano SL-C7000-5, NEXUS, REVO SHIFTER, 5s |
| Cassette |
Gates Carbon, CDX Rear Sprocket, 28T, Shimano Nexus 5 Mech. Hub 6-Lobe “Unified” Sprocket for 45,5 mm Beltline |
| Chain |
GATES CARBON DRIVE CDX BELT, 1298 MM LENGTH, 11 MM PITCH, 12 MM WIDTH |
| Brakes |
SHIMANO BR-MT200, W/180MM FRONT & REAR ADAPTERS, RESIN PAD Type:Â Hydraulic Disc |
Wheels
| Rims |
VELOMANN EBIKE MAXX 29″ – 622X25C |
|---|---|
| Front Hub |
SHIMANO HB-MT400-B CENTER LOCK, 15X110MM TA |
| Rear Hub |
SHIMANO NEXUS SG-C7000-5D 5SP, CENTER LOCK |
| Tires |
SCHWALBE MARATHON E-PLUS 55-622 28X2.15 |
| Disc Rotors |
Shimano SM-RT10, diam. 180mm |
Electric Components
| Motor |
BOSCH PERFORMANCE LINE CX 250W 85NM |
|---|---|
| Battery |
BOSCH POWERTUBE 625WH |
Accessories
| Lights |
Front: INTEGRATED CUSTOM FRONT AND SIDE LIGHT MADE W/SPANNINGA, Rear: Spanninga integrated rear lights |
|---|---|
| Fenders |
SKS PET MUDGUARDS A65 R |
| Racks |
Rear: custom rear carrier integrated into the frame design |
