Build
| Frame | e-Omnia T Type ALU, sizes: MD, LG, XL (43,48,53), 12x148mm Thru-axle, Ready to fix the chainguard, Post mount 160 disc brake type, Ready to fix rear kyckstand, custom rearcarrier integrated in the frame design, BatteryWall Darfon OmniaX/T/FX, Set dropout Colors: Bk – Black Glossy; 3i – Blue |
|---|---|
| Fork | Suntour XCM34-Boost NLO DS 15AH2-110 29″ travel 120mm Travel: 120mm Spring Type: Coil |
| Bottom Bracket | Included w/motor unit |
| Headset | Fsa NO.55R/558 1.5″ |
| Stem | VELOMANN HI-RISE STEM, EXT: 90MM-43/48CM, 110MM-53CM |
| Handlebar | VELOMANN Rise, width 740mm, diam. 31,8mm, 9 backsweep, 15mm rise |
| Saddle | Velomann 8016HR0, size 270x162mm |
| Seatpost | Velomann, lenght 350mm-15/17” and 400mm-19/21”, diam.31,6mm, 0mm seatback, AL2014 shaft Type: Rigid |
| Grips | HERRMANS LUNA LOCK |
Groupset
| Rear Derailleur | Shimano RD-M5120, DEORE, SGS 10sp, SHADOW DESIGN |
|---|---|
| Crank | FSA Die cast alloy, crank lenght 170mm ISIS black, MegaTooth 38T |
| Shifters | Shimano Deore SL-M4100-R, 10sp |
| Cassette | Shimano DEORE CS-M4100-10, 11-42T |
| Chain | Kmc e10S NPBK Anti-Rust 1/2″ x 11/128″ EPT |
| Brakes | Shimano BR-MT200, resin pad Type: Hydraulic Disc |
Wheels
| Rims | VELOMANN EBIKE MAXX 29″ – 622X25C |
|---|---|
| Front Hub | SHIMANO HB-MT400-B CENTER LOCK, 15X110MM TA |
| Rear Hub | SHIMANO FH-MT400-B CENTER LOCK, BOOST 12X148MM |
| Tires | WTB Slick 2.2 29″ 54/54 27tpi |
| Disc Rotors | Shimano SM-RT10, diam. 180mm |
Electric Components
| Motor | BOSCH PERFORMANCE LINE CX 250W 85NM |
|---|---|
| Battery | BOSCH POWERTUBE 500WH |
Accessories
| Lights | Front: INTEGRATED CUSTOM FRONT AND SIDE LIGHT MADE W/SPANNINGA, Rear: Spanninga integrated rear lights |
|---|---|
| Fenders | BIANCHI CUSTOM MUDGUARDS |
| Racks | Rear: custom rear carrier integrated into the frame design |
