Build
| Frame |
e-Omnia T Type Step Thru ALU, sizes: MD, LG, XL (43,48,53), 12x148mm Thru-axle, Ready to fix the chainguard, Post mount disc brake type, Ready to fix rear kyckstand, customrear carrier integrated in the frame design, BatteryWall Darfon OmniaX/T/FX, Set dr Colors:Â Bk – Black Glossy; 3f – Bordeaux |
|---|---|
| Fork |
Suntour XCM34-Boost NLO DS 15AH2-110 29″ travel 120mm Travel:Â 120mm Spring Type:Â Coil |
| Bottom Bracket |
Included w/motor unit |
| Headset |
Fsa NO.55R/558 1.5″ |
| Stem |
VELOMANN HI-RISE STEM, EXT: 90MM-43/48CM, 110MM-53CM |
| Handlebar |
VELOMANN Rise, width 740mm, diam. 31,8mm, 9 backsweep, 15mm rise |
| Saddle |
Velomann 8016DR0, size 260x160mm |
| Seatpost |
Velomann, lenght 350mm-15/17” and 400mm-19/21”, diam.31,6mm, 0mm seatback, AL2014 shaft Type:Â Rigid |
| Grips |
HERRMANS LUNA LOCK |
Groupset
| Rear Derailleur |
Shimano RD-M5120, DEORE, SGS 10sp, SHADOW DESIGN |
|---|---|
| Crank |
FSA Die cast alloy, crank lenght 170mm ISIS black, MegaTooth 38T |
| Shifters |
Shimano Deore SL-M4100-R, 10sp |
| Cassette |
Shimano DEORE CS-M4100-10, 11-42T |
| Chain |
Kmc e10S NPBK Anti-Rust 1/2″ x 11/128″ EPT |
| Brakes |
Shimano BRMT200, resin pad Type:Â Hydraulic Disc |
Wheels
| Rims |
VELOMANN EBIKE MAXX 29″ – 622X25C |
|---|---|
| Front Hub |
SHIMANO HB-MT400-B CENTER LOCK, 15X110MM TA |
| Rear Hub |
SHIMANO FH-MT400-B CENTER LOCK, BOOST 12X148MM |
| Tires |
WTB Slick 2.2 29″ 54/54 27tpi |
| Disc Rotors |
Shimano SM-RT10, diam. 180mm |
Electric Components
| Motor |
BOSCH PERFORMANCE LINE CX 250W 85NM |
|---|---|
| Battery |
BOSCH POWERTUBE 500WH |
Accessories
| Lights |
Front: INTEGRATED CUSTOM FRONT AND SIDE LIGHT MADE W/SPANNINGA, Rear: Spanninga integrated rear lights |
|---|---|
| Fenders |
BIANCHI CUSTOM MUDGUARDS |
| Racks |
Rear: custom rear carrier integrated into the frame design |
