Build
| Frame | e-VERTIC C-Type ALU sizes: 43, 48, 53 – 9×135 mm quick release dropouts – Post mount 180 disc brake type – Internal cable routing in steerer – 625Wh compatible Colors: T5 – Champagne / Graphite Race Matt; T6 – Blue Gray |
|---|---|
| Fork | Suntour NVX30 NLO DS 29″, 100mm travel, 1.1/8″ straight HT, w/out 9×100 QR, minimum 160mm rotor, maximum 180mm rotor, 30mm stanchions Travel: 100mm Spring Type: Coil |
| Bottom Bracket | incluso nel motore |
| Headset | Acros Headset 1,5″ top / 1,5″ – integrated cable routing |
| Stem | Velomann aluminium adjustable, integrated cable routing, Barbore 31,8 mm, Extension 90 mm |
| Handlebar | Velomann 31.8/680mm, RISE 20MM, SWEEP 15 |
| Saddle | Velomann, size 270x162mm, 385gr. |
| Seatpost | Velomann travel 50mm, suspension seatpost 300mm for size 43 350mm for sizes 48, 53 Type: Suspension |
| Pedals | VP, axle 7mm boron steel, EPB system, size 112×83,3mm, reflector included |
| Grips | Herrmans GRIPset Oxy |
Groupset
| Rear Derailleur | Shimano, RD-M4120, DEORE, SGS 10/11-SPEED |
|---|---|
| Crank | FSA CK-200, Alloy, 170mm FSA Steel Chainring 38T |
| Shifters | Shimano, SL-M4100-R, DEORE, 10-SPEED |
| Chain | KMC e10S NPBK |
| Brakes | Promax, DSK-925 Type: Hydraulic Disc |
Wheels
| Rims | EBIKE 650 TR 28″ – ETRTO 622 x 23C, 32hole, height 18mm |
|---|---|
| Front Hub | Shimano, HB-TX505,32H OLD:100MM AXLE:108MM, QR:133MM |
| Rear Hub | Shimano, FH-TX505-8, 32H 8/9/10/11-SPEED,OLD:135MM,AXLE:146MM,QR:170MM |
| Tires | Continental 50-622 eContact Plus |
| Disc Rotors | Promax DSK-925, 180mm, center lock |
Electric Components
| Motor | Bosch Performance Line, 250W, 65Nm, Purion display |
|---|---|
| Battery | Bosch Powertube 500Wh integrated battery |
Accessories
| Lights | Front: Lezyne, 65 lux, Rear: Trelock RearLight MudGuard Ebike6-12V |
|---|---|
| Fenders | Racktime Alumee 62mm, 28″ |
| Racks | Rear: Racktime, 28″, Max load 25Kg |
