Build
| Frame |
e-VERTIC C-Type ALU sizes: 43, 48, 53 – 9×135 mm quick release dropouts – Post mount 180 disc brake type BB Standard:Â Bosch, Press Fit Colors:Â T5 – Champagne / Graphite Race Matt; T6 – Blue Grey / Graphite Race Matt |
|---|---|
| Fork |
Suntour 29″, travel 100mm, COIL w/Preload adjuster, CR plating, Pitch 130 mm, 1-1/8″(TS), OLD 9-100, max rotor 180, post mount 160mm direct Travel:Â 100mm Spring Type:Â Coil |
| Bottom Bracket |
included in the motor |
| Headset |
SeatpLock SET AL bk T-Tronik + Omnia Screw M5x40, CH, hex, black Seatclamp Rubber Cover Omnia |
| Stem |
Velomann, 28,6 mm steerer ID Clamp, 31,8 mm barbore |
| Handlebar |
Velomann 31.8/680mm, RISE 20MM, SWEEP 15 |
| Saddle |
Velomann, steel rail, black cover 8067, 254x183mm, 420gr. |
| Seatpost |
Velomann, lenght 350mm for SM size and 400mm for MD, LG, diam.31,6mm, 0mm seatback Type:Â Rigid |
| Grips |
Herrmans, 130mm/130mm, d.22mm |
Groupset
| Rear Derailleur |
SRAM RD X7 SHORT CAGE ALUMINUM 9sp |
|---|---|
| Crank |
FSA E-Bike Diecast Crankset – CK220 Gen 3 / 170mm / Die cast aluminum FSA Direct Mount Steel Chainring – 38T / w/HT Steel / ED / C.L. 50mm Bosch Gen3 Bolt – Bosch Gen3 crank bolt Black |
| Shifters |
SRAM X5 TRIGGER REAR 9-SPD BLK 2200MM CABLE |
| Chain |
KMC e9S NPBK 1/2″ x 11/128″ |
| Brakes |
Shimano, BL-MT200, BR-MT200, BLACK, SM-MA-F180P/P2, RESIN PAD, 1000MM HOSE / 1700 HOSE Type:Â Hydraulic Disc |
Wheels
| Front Hub |
Shimano, 32H OLD:100MM AXLE:108MM, FOR CENTER LOCK ROTOR, QR:133MM W/O ROTOR MOUNTCOVER |
|---|---|
| Rear Hub |
Shimano, FOR CENTER LOCK ROTOR, 32H 8/9/10-SPEED,OLD:135MM,AXLE:146MM,QR:170MM, W/O ROTOR MOUNTCOVER |
| Tires |
Chaoyang E-Liner City 700x45C, 60tpi, Rhino Skin / SPS |
| Disc Rotors |
Shimano, M 180MM, W/LOCK RING, FOR RESIN PAD ONLY |
Electric Components
| Motor |
Bosch Active Plus motor unit |
|---|---|
| Battery |
Bosch Powertube 400wh integrated battery |
Accessories
| Lights |
Front: Lezyne, 65 lux, Center mount, 140cm cable w/ Bosch connector, w/ reflector, Rear: Trelock Ebike6-12V |
|---|---|
| Fenders |
Racktime Alumee 62mm, 28″, AL 6063-T4, black |
| Racks |
Rear: Racktime, 28″, Max load 25Kg, black, IMM mounting |
