Build
| Frame | e-VERTIC FT-Type ALU sizes: 43, 48, 53 – 12×148 mm thru axle dropouts – Post mount 180 disc brake type – 140mm travel front & rear – Internal cable routing in steerer Colors: 5v – Emerald / Green Race Matt; Rv – Brown / Graphite Race Matt |
|---|---|
| Fork | SRAM RockShox Recon Silver RL 29″, 140mm travel, 1.5″ tapered HT, Maxle Lite 15x110mm BOOST axle, minimum 160mm rotor, maximum 220mm rotor, 42mm rake, 61mm crown, Solo Air, extl rebnd, 32mm stanchions Travel: 140mm Spring Type: Air |
| Shock | RockShox Deluxe Select, 210/55, DebonAir Progressive, Damper Type R, Compression tune L, Lockout Force n/a, black finish tube, external rebound adjustment, Volume reducer 0 Neg 2 Pos Travel: 140mm |
| Bottom Bracket | included in the motor |
| Headset | Acros AZX-670 1.8″ top / 1.5″ – internal cable routing |
| Stem | Velomann, 50mm, 35mm, 1″1/8 |
| Handlebar | Velomann, width 780mm, diam.35mm, rise 18mm, backsweep 8 |
| Saddle | Velomann 260x160mm, 365gr. |
| Seatpost | Velomann, lunghezza 350 mm per la taglia SM e 400 mm per la MD, diametro 31,6 mm, schienale 0 mm Type: Rigid |
| Pedals | Fasten, w/ED steel cage, Boron ED black axle, BS reflector |
| Grips | T-One Rock T-GP34 single lock grip, TPR, 130mm, plastic inner body, aluminium clamp |
Groupset
| Rear Derailleur | SRAM SX Eagle, 12sp |
|---|---|
| Crank | FSA CK-320/IS/Gen4 FSA E-Bike Diecast Crankset ISIS / 165mm / Die cast aluminum |
| Shifters | SRAM SX EAGLE 1×12 |
| Chain | SRAM SX EAGLE, 12v |
| Brakes | Shimano, BL-M4100, BR-MT420, 4 pistons Type: Hydraulic Disc |
Wheels
| Rims | Velomann E-Sport Tubeless Ready 29″, 25-622, 32 hole |
|---|---|
| Front Hub | Formula CL-811 for Center Lock, 32h, 15x110mm TA |
| Rear Hub | Formula CL-3248 for Center Lock, 32h, 12x148mm TA, HG, 2SB |
| Tires | Schwalbe SUPERMOTO perf DD.raceguard 62-622 (29×2.4) |
| Disc Rotors | Shimano, SM-RT30, L 203MM |
Electric Components
| Motor | Bosch Performance Line CX, 250W, 85Nm, Kiox display |
|---|---|
| Battery | Bosch Powertube 750Wh integrated battery |
Accessories
| Lights | Front: Lezyne, 115 lux, 310 lumen, Rear: Trelock RearLight MudGuard Ebike6-12V |
|---|---|
| Fenders | Racktime Alumee 72mm, 28″ |
| Racks | Rear: Racktime luggage stay set, 29″, Max load 15Kg |
