Build
| Frame |
e-VERTIC FX-Type Pro – full carbon sizes: 43, 48, 53 – 12×148 mm thru axle dropouts – Post mount 180 disc brake type – 160mm travel front & rear – Internal cable routing in steerer Color:Â E3 – Iridescent Green / Anthracite |
|---|---|
| Fork |
RockShox ZEB 29″, 160mm travel, 1.5″ tapered HT, Maxle Ultimate 15x110mm BOOST axle, minimum 200mm rotor, maximum 220mm rotor, 44mm rake, 63mm crown, DebonAir Travel:Â 160mm Spring Type:Â Air |
| Shock |
RockShox Deluxe Select +, 230/65, DebonAir Progressive, Damer Type RT, Compression Tune L, Lockout Force 380, black finish tube, external rebound adjustment, Volume reducer 0 Neg 1 Pos Travel:Â 160mm |
| Bottom Bracket |
included in the motor |
| Headset |
Acros AIX-545 1.8″ top / 1.5″ – internal cable routing |
| Stem |
Velomann, 50mm, 35mm, 1″1/8 |
| Handlebar |
Velomann, width 780mm, diam.35mm, rise 18mm, backsweep 8 |
| Saddle |
Velomann Gnd Full-fit Start Up, carbon steel rail, 262×145 |
| Seatpost |
Velomann, diam.31,6mm, internal remote cable routing, 120mm/150mm travel – 120mm for size 43 – 150mm for sizes 48, 53 Type:Â Dropper |
| Grips |
T-One Rock T-GP34 single lock grip, TPR, 130mm, plastic inner body, aluminium clamp |
Groupset
| Rear Derailleur |
SRAM GX Eagle, 12sp |
|---|---|
| Crank |
FSA CK-320/IS/Gen4 FSA E-Bike Diecast Crankset ISIS / 165mm / Die cast aluminum SRAM X-SYNC 2 Eagle Chainring, 34T |
| Shifters |
SRAM NX EAGLE 1×12 |
| Chain |
SRAM GX EAGLE, 12sp |
| Brakes |
Magura MT Thirty Type:Â Hydraulic Disc |
Wheels
| Rims |
Velomann Tubeless Ready 29″, 622×30, 32 hole |
|---|---|
| Front Hub |
Formula CL-811 per fissaggio centrale, 32h, 15x110mm TA |
| Rear Hub |
Formula CL-1481, for Center Lock, 32h, 12x148mm TA |
| Tires |
Vittoria e-Barzo 29×2.6 XC-Trail TNT |
| Disc Rotors |
Magura MDR-C Centerlock – 203 mm |
Electric Components
| Motor |
Bosch Performance Line CX, 250W, 85Nm, Kiox display |
|---|---|
| Battery |
Bosch PowerTube 750Wh integrated battery |
