Build
| Frame | e-VERTIC FX-Type sizes: 43, 48, 53 – 12×148 mm thru axle dropouts – Post mount 180 disc brake type – 140mm travel front & rear – Internal cable routing in steerer Colors: E4 – Graphite Race Matt / Ck16 Matt; V6 – Graphitematt / Sagematt |
|---|---|
| Fork | RockShox 35 Silver TK 29″, 140mm travel, 1.5″ tapered HT, Maxle Stealth 15x110mm BOOST axle, minimum 180mm rotor, maximum 220mm rotor, 44mm rake, 61mm crown, Solo Air Travel: 140mm Spring Type: Air |
| Shock | RockShox Deluxe Select, 210/55, DebonAir Progressive, Damper Type R, Compression tune L, Lockout Force n/a, black finish tube, external rebound adjustment, Volume reducer 0 Neg 2 Pos Travel: 140mm |
| Bottom Bracket | included in the motor |
| Headset | Acros AZX-670 1.8″ top / 1.5″ – internal cable routing |
| Stem | Velomann, 50mm, 35mm, 1″1/8 |
| Handlebar | Velomann, width 780mm, diam.35mm, rise 18mm, backsweep 8 |
| Saddle | Velomann Gnd Full-fit Start Up, carbon steel rail, 262×145 |
| Seatpost | Velomann, diam.31,6mm, internal remote cable routing, 120mm/150mm travel – 120mm for size 43 – 150mm for sizes 48, 53 Type: Dropper |
| Grips | T-One Rock T-GP34 single lock grip, TPR, 130mm, plastic inner body, aluminium clamp |
Groupset
| Rear Derailleur | SRAM SX Eagle, 12sp |
|---|---|
| Crank | FSA E-Bike Diecast Crankset ISIS / 165mm / Die cast aluminum SRAM X-SYNC 2 Eagle Chainring, 34T |
| Shifters | SRAM SX EAGLE 1×12 |
| Chain | SRAM SX EAGLE, 12sp |
| Brakes | Shimano, BL-M4100, BR-MT420, 4 pistons Type: Hydraulic Disc |
Wheels
| Rims | Velomann Tubeless Ready 29″, 622×30, 32 hole |
|---|---|
| Front Hub | Formula CL-811 for Center Lock, 32h, 15x110mm TA |
| Rear Hub | Formula CL-3248 for Center Lock, 32h, 12x148mm TA |
| Tires | Vittoria e-Barzo 29×2.6 XC-Trail TNT |
| Disc Rotors | Shimano, SM-RT30, L 203MM |
Electric Components
| Motor | Bosch Performance Line CX, 250W, 85Nm, Kiox display |
|---|---|
| Battery | Bosch PowerTube 750Wh integrated battery |
