Build
| Frame | e-VERTIC X/T-Type ALU sizes: 43, 48, 53 – 9×135 mm quick release dropouts – Post mount 180 disc brake type BB Standard: Bosch, Press Fit Colors: Eg – Emerald Green / Graphite Race Glossy; Sv – Light Grey / Graphite Race Glossy |
|---|---|
| Fork | Suntour 29″, travel 100mm, COIL w/Preload adjuster, CR plating, Pitch 130 mm, 1-1/8″(TS), OLD 9-100, max rotor 180, post mount 160mm direct Travel: 100mm Spring Type: Coil |
| Bottom Bracket | included in the motor |
| Headset | Acros 1,5″” top / 1,5″” bottom – bearings – integrated cable routing 1 1/8 crown race for ZS56 Head tube cover |
| Stem | Velomann, integrated cable routing, Barbore 31,8 mm, Extension 90 mm |
| Handlebar | Velomann, 31.8*630 / Rise 34mm / Back Sweep 41 |
| Saddle | Velomann, black cover 8067 size 270x162mm, 385gr. |
| Seatpost | Velomann LT2 31.6*350 travel 50mm Type: Dropper |
| Grips | Herrmans, 130mm/130mm, d.22mm |
Groupset
| Rear Derailleur | SRAM RD X7 SHORT CAGE ALUMINUM 9sp |
|---|---|
| Crank | FSA E-Bike Diecast Crankset – CK220 Gen 3 / 170mm / Die cast aluminum FSA Direct Mount Steel Chainring – 38T / w/HT Steel / ED / C.L. 50mm Bosch Gen3 Bolt – Bosch Gen3 crank bolt Black |
| Shifters | SRAM X5 TRIGGER REAR 9sp BLK 2200MM CABLE |
| Chain | KMC e10S NPBK 1/2″ x 11/128″ |
| Brakes | Shimano, BL-MT200, BR-MT200, BLACK, SM-MA-F180P/P2, RESIN PAD, 1000MM HOSE / 1700 HOSE Type: Hydraulic Disc |
Wheels
| Front Hub | Shimano, 32H OLD:100MM AXLE:108MM, FOR CENTER LOCK ROTOR, QR:133MM W/O ROTOR MOUNTCOVER |
|---|---|
| Rear Hub | Shimano, FOR CENTER LOCK ROTOR, 32H 8/9/10-SPEED,OLD:135MM,AXLE:146MM,QR:170MM, W/O ROTOR MOUNTCOVER |
| Tires | Continental CONTACT Urban |
| Disc Rotors | Shimano, M 180MM, W/LOCK RING, FOR RESIN PAD ONLY |
Electric Components
| Motor | Bosch Active Plus motor unit |
|---|---|
| Battery | Powertube 400wh integrated battery |
Accessories
| Lights | Front: Lezyne, 65 lux, Center mount, 140cm cable w/ Bosch connector, w/ reflector, Rear: Trelock Ebike6-12V |
|---|---|
| Fenders | Racktime Alumee 62mm, 28″, AL 6063-T4, black |
| Racks | Rear: Racktime, 28″, Max load 25Kg, black, IMM mounting |
