Build
| Frame |
e-VERTIC X-Type ALU sizes: 43, 48, 53 – 9×135 mm quick release dropouts – Post mount 180 disc brake type – 120mm travel front – Internal cable routing in steerer – 625Wh compatible Colors:Â Tc – Graphite Race / Ck16 Glossy; Th – Gray |
|---|---|
| Fork |
Suntour XCR34-AIR-Boost LOR DS 15QLC32-110 29″, 120mm travel, 1.5″ tapered HT, Thru Axle 15QLC32-110, minimum 180mm rotor, maximum 203mm rotor, Damper Type LOR, 34mm stanchions, Air Travel:Â 120mm Spring Type:Â Air |
| Bottom Bracket |
included in the motor |
| Headset |
Acros AZF-575 1.8″ top / 1.5″ – internal cable routing |
| Stem |
Velomann Viper0, 60mm, 31.8 mm, 1″1/8 |
| Handlebar |
Velomann, width 740mm, diam 31.8mm, rise 15mm, backsweep 9 |
| Saddle |
Velomann Gnd Full-fit Start Up, carbon steel rail, 262×145 |
| Seatpost |
Velomann, diam.31,6mm, 0mm seatback, 300mm size 43 350mm size 48 400mm size 53 Type:Â Rigid |
| Grips |
T-One Rock T-GP34 single lock grip, TPR, 130mm, plastic inner body, aluminium clamp |
Groupset
| Rear Derailleur |
Shimano, RD-M4120, DEORE, SGS 10/11-SPEED |
|---|---|
| Crank |
FSA CK-320/IS/Gen4 FSA E-Bike Diecast Crankset ISIS / 165mm / Die cast aluminum, FSA Steel MegaTooth Chainring 34T |
| Shifters |
Shimano, SL-M4100-R, DEORE, 10-SPEED |
| Chain |
KMC e10S NPBK |
| Brakes |
Promax DSK-925 Type:Â Hydraulic Disc |
Wheels
| Rims |
Velomann E-Sport Tubeless Ready 29″, 622×25, 32 hole |
|---|---|
| Front Hub |
Formula CL-811 for Center Lock, 32h, 15x110mm TA |
| Rear Hub |
Formula CL-1422, CENTER LOCK, FOR SHIMANO MTB 8/ 9/ 10/ 11-SPEED – O.L.D. 135 mm – AXLE 145 mm |
| Tires |
Chaoyang Phantom dry 29×2.3, 60tpi |
| Disc Rotors |
Promax DSK-925, 180mm, center lock |
Electric Components
| Motor |
Bosch Performance Line CX, 250W, 85Nm, Purion display |
|---|---|
| Battery |
Bosch Powertube 625Wh integrated battery |
