Build
| Frame | T-Tronik C-Type Frame 28″ Urban, Suspended fork geometry, Alu PG 6061 32/37 Max shell, disc brake, O.L.D.135mm, D/T battery, size: 43/47 Colors: Gt – Blu Stone / Dark Graphite Full Matt; Jt – Iridescent Bronze / Dark Graphite Full Matt |
|---|---|
| Fork | Suntour SF15-NEX-E25-DS-700C-63 PostMount disc brake, 1.1/8″”, travel 63mm, compatible with fender, OLD 100mm, Quick relase type Travel: 63mm Spring Type: Coil |
| Bottom Bracket | included in the motor |
| Headset | FSA 1.1/8″ 44H-N10P |
| Stem | Velomann, 28,6 mm steerer ID Clamp, 31,8 mm barbore |
| Handlebar | Velomann 31.8/680mm, RISE 20MM, SWEEP 15 |
| Saddle | Selle Royal, Essenza |
| Seatpost | Velomann, lenght 350mm, diam. 31,6mm, 0mm seatback, Al2014 shaft + alloy head Type: Rigid |
| Pedals | VP black aluminum, w/reflector |
| Grips | Herrmans GRIPset Oxy DD29BR/BL 130mm/130mm black-black,d.22mm |
Groupset
| Rear Derailleur | Sunrace, 9sp, max 42T |
|---|---|
| Crank | FSA SMN E-Bike Forged Crankset, 170mm CHAINRING, SM-CRE61, 38T, FOR CHAIN LINE 46.5MM |
| Shifters | Sunrace DLE903N, 9sp, w/ optical gear |
| Chain | KMC E9s EPT |
| Brakes | Radius, BH-M960, 900mm hose length, Direct Mount, w/adapter Radius BH-M960, 1700mm hose length, Direct Mount, w/ J-kit, w/ adapter Type: Rim |
Wheels
| Rims | Velomann 29″, 23-622, 32 hole black |
|---|---|
| Tires | Chaoyang E-Liner City 700x45C, 60tpi |
| Disc Rotors | Radius Rotors RT900, 160mm, center lock |
Electric Components
| Motor | Shimano E6100 250W, torque 60Nm |
|---|---|
| Battery | 417Wh Phylion integrated battery |
Accessories
| Lights | Front: Herrmans Mr GO, Rear: Axa Juno |
|---|---|
| Fenders | SKS Mudguard profile A60S, internal cable routing on the rear mudguard, secuclip/esc clip, protector on front and rear tail, protector on front mudguard |
| Racks | Rear: Racktime, RT Eco 2.0, 28″, black w/ roundstay 350mm |
