Build
| Frame |
T-Tronik T-Type Step-through ALU sizes: 43, 47 – 9×135 mm quick release dropouts – Post mount 160 disc brake type Colors:Â 2t – Green / Dark Graphite Full Matt; Ty – Urban Gray / Dark Graphite Full Matt |
|---|---|
| Fork |
Suntour NEX-E25 DS 700C, 63mm travel, 1-1/8″ HT,w/out 9×100 QR, minimum 160mm rotor, maximum 180mm rotor, 30mm stanchions Travel:Â 63mm Spring Type:Â Coil |
| Bottom Bracket |
included in the motor |
| Headset |
FSA HST STbk 1-1/8″ 44H-N10P |
| Stem |
Velomann, 28,6 mm steerer ID Clamp, 31,8 mm |
| Handlebar |
Velomann 31.8/680mm, RISE 20MM, SWEEP 15 |
| Saddle |
Selle Royal |
| Seatpost |
Velomann, lenght 350mm for SM size and 400mm for MD, diam.31,6mm, 0mm seatback Type:Â Rigid |
| Pedals |
VP black aluminum, axle 7mm, 113,5×110,5mm |
| Grips |
Herrmans GRIPset Oxy |
Groupset
| Rear Derailleur |
SRAM X7, 9sp, max. 36T |
|---|---|
| Crank |
Shimano CHAINRING, SM-CRE61, 38T FSA SMN E-Bike Forged Crankset – SMN / 170mm |
| Shifters |
SRAM X5, 9sp |
| Chain |
KMC e9S NPBK |
| Brakes |
Promax, DSK-925 Type:Â Hydraulic Disc |
Wheels
| Rims |
EBIKE 650 TR 28″ – ETRTO 622 x 23C, 32hole, height 18mm |
|---|---|
| Front Hub |
Shimano, HB-TX505,32H OLD:100MM AXLE:108MM, QR:133MM |
| Rear Hub |
Shimano, FH-TX505-8, 32H 8/9/10/11-SPEED,OLD:135MM,AXLE:146MM,QR:170MM |
| Tires |
Chaoyang E-Liner City 700x45C, 60tpi |
| Disc Rotors |
Promax DSK-925, 160mm, center lock |
Electric Components
| Motor |
Shimano E6100, 250W, 60Nm |
|---|---|
| Battery |
417Wh integrated battery |
Accessories
| Lights |
Front: Herrmans Mr GO e-bike 6/12 V, Rear: Axa Juno e-bike 6/12 V |
|---|---|
| Fenders |
SKS PET Mudguards A60 S /28″ |
| Racks |
Rear: Racktime, 28″, Max load 25Kg |
