Build
| Frame |
Intube Bosch, Gen.4, BES3, aluminium, trapeze, 41cm BB Standard:Â Bosch, Press Fit Colors:Â Red; Grey |
|---|---|
| Fork |
ROCKSHOX suspension fork “Recon Silver RL”, 29″, 120mm travel, tapered, post mount, boost, Maxle Lite thru axle, 51mm offset, black Travel:Â 120mm Spring Type:Â Air |
| Bottom Bracket |
Bosch, press-fit |
| Headset |
ACROS ZS56/28,6 / ZS56/40, 1 1/8″ – 1,5″ tapered, 120 blocklock below |
| Stem |
LEVELNINE “Team A-Head”, 1 1/8″, 31,8mm handlebar clamp, 40mm long, black |
| Handlebar |
LEVELNINE “Race Riser”, 780mm, 31,8mm, backsweep 9, rise 15mm, black |
| Saddle |
SELLE ROYAL “Vivo”, ladies, athletic, black |
| Seatpost |
CONWAY, 27,2mm, 350mm long, 10mm offset, black Type:Â Rigid |
| Pedals |
VP COMPONENTS “VPE-506” |
| Grips |
SQLAB “70X”, size M, 135mm, black |
Groupset
| Rear Derailleur |
SRAM “NX Eagle” |
|---|---|
| Crank |
MIRANDA “Classic”, boost, 170mm, 36 teeth, for Bosch Gen.4, ISIS, chain guard ring |
| Shifters |
SRAM “SX Eagle”, single click, 12-speed |
| Cassette |
SRAM “PG-1230” Eagle, 12-speed Eagle, 11-50 teeth |
| Brakes |
hydraulic disc brake Type:Â Hydraulic Disc |
Wheels
| Rims |
CROSS “X18”, 30-622, 32 holes, disc brake, eyelets, black |
|---|---|
| Spokes |
Niro, schwarz |
| Front Hub |
PROMAX “DR850F”, 15 x 110mm boost, Center Lock, 32 holes, thru axle, black |
| Rear Hub |
SHIMANO “Alivio FH-MT400-B”, 12 x 148mm, Center Lock, 8-/9-/10-speed (11-speed MTB), 32 holes, thru axle, black |
| Tires |
SCHWALBE “Johnny Watts” Performance Line, 65-622, DD, Race Guard, Addix, foldable, 67 TPI, E-50, reflex |
Electric Components
| Motor |
BOSCH “Performance Line CX” Gen.4, BES3 |
|---|---|
| Battery |
BOSCH “PowerTube 750”, 750 Wh, BES3, horizontal |
| Remote |
BOSCH “BRC3600”, LED remote |
| Display |
BOSCH “Kiox 300”, 4-stages, remote control, push aid |
| Charger |
BOSCH 4 A, BES3 |
