Build
Frame |
Intube Bosch, Gen.4, BES3, aluminium, trapeze, 41cm BB Standard:Â Bosch, Press Fit Colors:Â Black; Gold |
---|---|
Fork |
FOX RACING SHOX suspension fork “Float AWL”, 29″, 120mm travel, tapered, post mount, boost, thru axle, 51mm offset, black Travel:Â 120mm Spring Type:Â Air |
Bottom Bracket |
Bosch, press-fit |
Headset |
ACROS ZS56/28,6 / ZS56/40, 1 1/8″ – 1,5″ tapered, 120 blocklock below |
Stem |
LEVELNINE “Adjustable”, 1 1/8″, 31,8mm handlebar clamp, 65mm long, black |
Handlebar |
LEVELNINE “Low Riser”, 720mm, 31,8mm, backsweep 9, upsweep 5, black |
Saddle |
SELLE ROYAL “Vivo”, gents, athletic, black |
Seatpost |
CONWAY, 27,2mm, 350mm long, 10mm offset, black Type:Â Rigid |
Pedals |
VP COMPONENTS “VPE-506” |
Grips |
CONWAY “Sport”, 130mm, black |
Groupset
Rear Derailleur |
SHIMANO “Deore XT RD-M8130-SGS”, LINKGLIDE, long cage |
---|---|
Crank |
MIRANDA “Classic”, boost, 170mm, 36 teeth, for Bosch Gen.4, ISIS, chain guard ring |
Shifters |
SHIMANO “Deore XT SL-M8130”, LINKGLIDE, 11-speed |
Cassette |
SHIMANO “CS-LG600”, LINKGLIDE, 11-speed, 11-50 teeth |
Brakes |
hydraulic disc brake Type:Â Hydraulic Disc |
Wheels
Rims |
CROSS “X18”, 30-622, 32 holes, disc brake, eyelets, black |
---|---|
Spokes |
Niro, schwarz |
Front Hub |
SHIMANO “Altus HB-MT400-B”, 15 x 110mm, Center Lock, 32 holes, thru axle, black |
Rear Hub |
SHIMANO “Alivio FH-MT400-B”, 12 x 148mm, Center Lock, 8-/9-/10-speed (11-speed MTB), 32 holes, thru axle, black |
Tires |
SCHWALBE “Johnny Watts” Performance Line, 60-622, DD, Race Guard, Addix, foldable, 67 TPI, E-50, reflex |
Electric Components
Motor |
BOSCH “Performance Line CX” Gen. 4, BES3 |
---|---|
Battery |
BOSCH “PowerTube 750”, 750 Wh, BES3, horizontal |
Remote |
BOSCH “BRC3600”, LED remote |
Display |
BOSCH “Kiox 300”, 4-stages, remote control, push aid |
Charger |
BOSCH 4 A, BES3 |
Accessories
Lights |
Front: LUPINE “SL Nano F”, 140 lux, handlebar bracket, 900 lumen daytime running light, 1300 Lumen high beam, 31,8mm handlebar bracket, Rear: CONTEC “TL-335 E-Stop”, distance between screws: 50mm, stoplight function |
---|---|
Fenders |
CURANA “Apollo 75”, aluminium, 75mm, matt black |
Racks |
ATRAN VELO “Commute Pro”, AVS system, F-Fix, black |
