Build
| Frame |
Intube EP8, aluminium, full suspension, 41cm BB Standard:Â BSA, 73mm, Threaded Colors:Â Grey; Orange |
|---|---|
| Fork |
ROCKSHOX suspension fork “35 Gold RL”, 29″, 160mm travel, tapered, post mount, boost, Maxle Lite thru axle, 44mm offset, black Travel:Â 160mm Spring Type:Â Air |
| Shock |
FOX “Float DPS”, 205 x 60mm 155 mm Travel:Â 155mm |
| Bottom Bracket |
BSA, 73mm, threaded |
| Headset |
ACROS ZS56/28,6 / ZS56/40, 1 1/8″ – 1,5″ tapered, 135 blocklock top |
| Stem |
ERGOTEC “Bass”, ahead 1 1/8″, 31,8mm handlebar clamp, 45mm long, angle 0, Level 6+, sandblasted black |
| Handlebar |
LEVELNINE “Race Riser”, 780mm, 31,8mm, backsweep 9, rise 15mm, black |
| Saddle |
FIZIK “Aidon X5”, unisex, type 2, regular, black |
| Seatpost |
CONTEC dropper seatpost “Drop-A-Gogo”, aluminium, 31,6mm, 340mm long, 100mm adjustable range, black Type:Â Dropper |
| Grips |
SQLAB “70X”, size M, 135mm, black |
Groupset
| Rear Derailleur |
SHIMANO “Deore RD-M5100” |
|---|---|
| Crank |
SHIMANO “Deore XT FC-M8150”, 165mm, Hollowtech II, for EP8, black |
| Shifters |
SHIMANO “Deore SL-M5100”, I-Spec, 11-speed |
| Cassette |
SHIMANO “Deore CS-M5100”, 11-speed, 11-51 teeth |
| Brakes |
hydraulic disc brake Type:Â Hydraulic Disc |
Wheels
| Rims |
RODI “Ready 35”, 35-622, 32 holes, disc brake, easy eyelets, black |
|---|---|
| Spokes |
Niro, schwarz |
| Front Hub |
SHIMANO “Altus HB-MT400-B”, 15 x 110mm, Center Lock, 32 holes, thru axle, black |
| Rear Hub |
SHIMANO “Alivio FH-MT400-B”, 12 x 148mm, Center Lock, 8-/9-/10-speed (11-speed MTB), 32 holes, thru axle, black |
| Tires |
SCHWALBE “Magic Mary”, Evolution Line 62-622, Super Trail, Addix Soft, TLE, foldable, 50 TPI, E-50 |
Electric Components
| Motor |
SHIMANO “EP800” |
|---|---|
| Battery |
DARFON “Intube 720”, 720 Wh |
| Remote |
SHIMANO “SW-EM800” |
| Display |
SHIMANO “SC-EM800”, 3-levels, remote control, push aid |
| Charger |
DARFON 4-5,6 A |
