Build
Frame |
6061-T6 aluminum BB Standard:Â BSA, Threaded |
---|---|
Fork |
Hi-ten steel unicrown, straight/tapered leg |
Bottom Bracket |
Torque sensor, threaded, 122.5mm spindle |
Headset |
1 1/8” steel threaded |
Stem |
Cast alloy 25.4mm quill, 92mm extension |
Handlebar |
Alloy custom bend low-rise, 640mm width |
Saddle |
Size: S, M, Retro leatherette w/dual spring; Size: S, M, Brooks Cambium C19 Special |
Seatpost |
Size: S, Alloy micro-adjust 27.2x350mm; Size: M, Alloy micro-adjust 27.2x400mm Type:Â Rigid |
Pedals |
Alloy platform w/non-slip rubber tread |
Grips |
Size: S, M, Electra custom hand-stitched; Size: S, M, Brooks Cambium |
Groupset
Rear Derailleur |
Shimano Tourney TY300 |
---|---|
Crank |
Forged alloy 170mm, 44t chainring w/chainguard |
Shifters |
Shimano Tourney Revo 7-speed twist with optical gear display |
Cassette |
7-speed freewheel 14-34t |
Chain |
KMC Z7, 7 speed |
Brakes |
Mechanical disc, 160mm rotor, flat-mount Type:Â Mechanical Disc |
Brake Levers |
Alloy, 3-finger |
Wheels
Rims |
Size: S, M, Alloy double walled 700x32h; Size: S, M, Alloy double walled 700x36h |
---|---|
Spokes |
Size: S, M, 14g stainless steel; Size: S, M, 13g stainless steel, silver; Size: S, M, 14g stainless steel, black; Size: S, M, 13g stainless steel, black |
Front Hub |
Alloy low-flange w/6-bolt disc, 32h, nutted |
Rear Hub |
Hyena hub motor w/6-bolt disc, 36h, nutted |
Tires |
700x40mm city tread |
Electric Components
Motor |
Hyena hub motor w/6-bolt disc, 36h, nutted |
---|---|
Battery |
250Wh, integrated in down tube Recycling Program:Â Â Call2Recycle |
Display |
LED display |
Charger |
2A, 42V output, 100V-240V AC input |
Accessories
Lights |
Size: S, M, Spanninga, LED, taillight; Size: S, M, Herrmans H-Black MR4-E, 120 Lumen, 40 Lux, LED, headlight |
---|---|
Fenders |
Alloy extruded, painted |
