Build
| Frame |
Fuji A6-SL alloy front and rear triangle with down tube for integrated Bosch Power Tube 625-500Wh battery, Bosch Gen.4 motor cover, tapered 1 1/8″ – 1.5″ head tube, post disc mount, Boost 148 x 12mm cold-forged dropout and replaceable hanger BB Standard:Â Bosch, Press Fit Color:Â Opal Green |
|---|---|
| Fork |
SR Suntour Zeron 27.5, Lockout, Rebound, Coil, tapered alloy steerer, Boost 110 x 15mm thru axle, travel 130mm, 35mm stanchions Travel:Â 130mm Spring Type:Â Coil |
| Bottom Bracket |
Bosch System ISIS Drive |
| Headset |
FSA NO.57B, 1 1/8″ – 1.5″, retainer bearings |
| Stem |
3D-forged 6061 alloy, 7 degree, 31.8mm clamp, length: 17″ – 35mm, 19″- 45mm, 21″ – 60mm |
| Handlebar |
Oval Concepts 205 flat bar, 6061 alloy, +/- 5mm rise, 9 degree sweep, 31.8mm clamp, width: 760mm |
| Saddle |
WTB High Tail Trail, Comp, e-Bike specific saddle, steel rail |
| Seatpost |
Oval Concepts 300, 6061 alloy micro adjust, 30.9mm diameter Type:Â Rigid |
| Pedals |
Alloy platform, chromoly axle |
| Grips |
WTB Waffel, single LO, dual density Kraton |
Groupset
| Rear Derailleur |
Shimano Deore |
|---|---|
| Crank |
FSA CK-745/IS, Bosch Gen.4, 32T, with chainguard, for Boost |
| Shifters |
Shimano Deore |
| Cassette |
Shimano Deore, 11-51T, 11-speed |
| Chain |
Shimano CN-HG601-11, 11-speed |
| Brakes |
TRP Slate-T4 and X2, 4-piston front, 2-piston rear hydraulic disc, rotors: 203mm front and rear Type:Â Hydraulic Disc |
| Brake Levers |
TRP Slate T4 hydraulic 2 finger lever |
Wheels
| Rims |
Shimano MT400-Boost CL 15mm thru axle disc, 32H, front / Shimano MT400-Boost CL 12mm thru axle disc, 32H, rear, 14/15g stainless steel spokes, WTB ST i29 TCS 2.0 double wall 27.5″ rims |
|---|---|
| Tires |
Continental Trail King, 70-584, ShieldWall, foldable, TL |
Electric Components
| Motor |
Bosch Performance CX, 4th generation mid-motor, 250W rated power, 85Nm of torque, 25km/h maximum assist |
|---|---|
| Battery |
Bosch Power Tube 500Wh w/ 2A charger Recycling Program:Â Â Call2Recycle |
| Display |
Bosch Purion |
