Build
| Frame | Fuji A6-SL alloy front and rear triangle with down tube for integrated Bosch Power Tube 625-500Wh battery, Bosch Gen.4 motor cover, tapered 1 1/8″ – 1.5″ head tube, post disc mount, Boost 148 x 12mm cold-forged dropout and replaceable hanger BB Standard: Bosch, Press Fit Color: Wet Gray |
|---|---|
| Fork | SR Suntour XCR34-Air 29, Lockout, tapered alloy steerer, Boost 110 x 15mm thru axle, travel 120mm, 34mm stanchions Travel: 120mm Spring Type: Air |
| Bottom Bracket | Bosch System ISIS drive |
| Headset | FSA NO.57B, 1 1/8″ – 1.5″, retainer bearings |
| Stem | 3D-forged 6061 alloy, 7, 31.8mm clamp, length: 17″ – 35mm, 19″- 45mm, 21″ – 60mm |
| Handlebar | Oval Concepts 205 flat bar, 6061 alloy, +/- 15mm rise, 9 sweep, 31.8mm clamp, width: 760mm |
| Saddle | WTB High Tail Trail, Comp, e-Bike specific saddle, steel rail |
| Seatpost | Fuji Alloy, 6061 alloy micro adjust, 30.9mm diameter Type: Rigid |
| Pedals | Alloy platform, chromoly axle |
| Grips | WTB Waffel, single LO, dual density Kraton |
Groupset
| Rear Derailleur | Shimano Deore |
|---|---|
| Crank | FSA CK-745/IS, Bosch Gen.4, 32T, with chainguard, for Boost |
| Shifters | Shimano Deore |
| Cassette | Shimano Deore, 11-51T, 11-speed |
| Chain | Shimano CN-HG601-11, 11-speed |
| Brakes | TRP Slate-T4 and X2, 4-piston front, 2-piston rear hydraulic disc, rotors: 203mm front and rear Type: Hydraulic Disc |
| Brake Levers | TRP Slate-T4, 2 finger lever |
Wheels
| Rims | Shimano MT400-Boost CL 15mm thru axle disc, 32H, front / Shimano MT400-Boost CL 12mm thru axle disc, 32H, rear, 14/15g stainless steel spokes, WTB ST i29 TCS 2.0 double wall 29″ rims |
|---|---|
| Tires | Continental Ruban, 58-622 |
Electric Components
| Motor | Bosch Performance CX, 4th generation mid-motor, 250W rated power, 85Nm of torque, 25km/h maximum assist |
|---|---|
| Battery | Bosch Power Tube 500Wh with 2A charger Recycling Program: Call2Recycle |
| Display | Bosch Purion |
Accessories
| Lights | Front: Lezyne Hecto E65, 65 Lux, 6-12V, with stem X-Lock mount, Rear: Herrmans H-Gargo Narrow, integrated with rear carrier |
|---|---|
| Fenders | Fuji Alloy Fender, Multi chamber extrusion |
| Racks | Rear: Standwell tubular aluminum, with CarryMore platform and spring clamp, integrated rear light |
