Build
| Frame |
Hydroformed Alloy, 26 Fatbike frame, internal cable routing head tube ported, removable down tube battery with security lock |
|---|---|
| Fork |
RST RENEGADE 26 suspension, 120mm travel, lockout, Thru Axle Travel:Â 120mm |
| Stem |
45mm with 3 degree rise, 31.8mm clamp dia. |
| Handlebar |
720mm, 28mm rise, 31.8mm dia. |
| Saddle |
SELLE ROYAL Viento |
| Seatpost |
EXA KSP900-1 Dropper Post, 150mm travel (445mm) Type:Â Dropper |
| Grips |
VELO, Rubber palm rest, 132mm |
Groupset
| Rear Derailleur |
SHIMANO ALIVIO 9-speed |
|---|---|
| Crank |
34T with Narrow Wide teeth |
| Shifters |
SHIMANO ALIVIO 9-speed Rapidfire Plus |
| Cassette |
SHIMANO ALIVIO 9-speed 11-36T |
| Chain |
KMC E9-S |
| Brakes |
TEKTRO HDE350 Hydraulic Disc Type:Â Hydraulic Disc |
| Brake Levers |
TEKTRO HDE350 with power cut off switch |
Wheels
| Rims |
26″x95mm Fat bike rim |
|---|---|
| Tires |
MAXXIS Minion M346(F) M347(R) 26×4.8 |
| Disc Rotors |
180mm |
Electric Components
| Motor |
iGO DRIVE RS 500W mid motor, 48V |
|---|---|
| Battery |
5000mAh SAMSUNG cell, removable with security lock (48V | 15Ah | 720Wh) |
| Display |
2 HD High Brightness IPS Color LCD Display, Ergonomically Designed Buttons, IP65 Waterproof, Password Protected Power On Option, USB Charging Port, Light Auto On/Off Option (Ambient Light Detector), Interface Color Coded Display Reference (for Quick Glance Safety), Main Power/PAS Control/Ride, Stats and Settings Toggle, PAS Level/Battery/Power/Clock, Speedometer/Max Speed/Avg Speed, Trip Distance, Battery Voltage/Capacity Percentage/Range/Accumulated Charging Cycles, Motor Power Output Average/Maximum, Ride Analysis Statistics, Diagnostic and Warning Information, Walk Assist |
