Build
| Frame | KELLYS E-CARSON R-series – advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / integrated removable battery, 1.5 tapered HT |
|---|---|
| Fork | ROCK SHOX Recon Silver RL (29″) Boost, 100 mm, Solo Air / Motion Control / Maxle Stealth 15 mm thru axle Travel: 100mm Spring Type: Air |
| Stem | PROMAX a-head adjustable – diam 28.6 mm / bar bore 31.8 mm / length 105 mm |
| Handlebar | KLS Active RiseBar – diam 31.8 mm / rise 18 mm / width 700 mm |
| Saddle | SELLE ROYAL Lookin Visual Royalgel |
| Seatpost | KLS Active – diam 30.9 mm / length 350 mm Type: Rigid |
| Pedals | plastic |
| Grips | KLS Wave 2Density ergonomic |
Groupset
| Rear Derailleur | SHIMANO Cues U6000 (direct mount) |
|---|---|
| Crank | MIRANDA Delta (36T) – length 170 mm |
| Shifters | SHIMANO Cues SL-U6000-10 Rapidfire Plus |
| Cassette | SHIMANO Linkglide CS-LG300-10 (11-48T) |
| Chain | SHIMANO Linkglide CN-LG500 (122 links) |
| Brakes | SHIMANO MT200 hydraulic disc Type: Hydraulic Disc |
| Brake Levers | SHIMANO BL-MT200 |
Wheels
| Rims | KLS Draft Disc 622×21 (32 holes) |
|---|---|
| Spokes | stainless steel black |
| Front Hub | SHIMANO MT400-B / Alivio M4050 Disc Center Lock (32 holes) |
| Rear Hub | SHIMANO MT400-B / Alivio M4050 Disc Center Lock (32 holes) |
| Tires | SCHWALBE Marathon Almotion Performance 55-622 (28″x2.15) ReflectiveLine |
| Disc Rotors | 180 mm front / 180 mm rear |
Electric Components
| Motor | PANASONIC GX Ultimate, 95 Nm, 36 V |
|---|---|
| Battery | KELLYS Re-Charge V10 Li-ion internal removable 725 Wh / capacity 20 Ah, powered by BMZ |
| Display | PANASONIC Bluetooth 5.0 navigation Side Color Display |
Accessories
| Lights | Front: TRELOCK Veo 50, Rear: TRELOCK Duo Flat |
|---|---|
| Fenders | aluminium |
