Build
| Frame | KELLYS E-CRISTY R-series – advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / integrated removable battery, 1.5 tapered HT |
|---|---|
| Fork | SR SUNTOUR NVX 30 NLO DS (29″), 100 mm, coil spring Travel: 100mm Spring Type: Coil |
| Stem | PROMAX a-head adjustable – diam 28.6 mm / bar bore 31.8 mm / length 85 mm |
| Handlebar | KLS Active RiseBar – diam 31.8 mm / rise 18 mm / width 700 mm |
| Saddle | SELLE ROYAL Vivo |
| Seatpost | KLS Active – diam 30.9 mm / length 350 mm Type: Rigid |
| Pedals | plastic |
| Grips | KLS Wave 2Density ergonomic |
Groupset
| Rear Derailleur | SHIMANO Cues U4000 (direct mount) |
|---|---|
| Crank | MIRANDA Delta (36T) – length 170 mm |
| Shifters | SHIMANO Cues SL-U4000-9 Rapidfire Plus |
| Cassette | SHIMANO Linkglide CS-LG300-9 (11-41T) |
| Chain | SHIMANO Linkglide CN-LG500 (122 links) |
| Brakes | SHIMANO MT200 hydraulic disc Type: Hydraulic Disc |
| Brake Levers | SHIMANO BL-MT200 |
Wheels
| Rims | KLS Draft Disc 622×21 (32 holes) |
|---|---|
| Spokes | stainless steel black |
| Front Hub | SHIMANO TX505 Disc Center Lock (32 holes) |
| Rear Hub | SHIMANO TX505 Disc Center Lock (32 holes) |
| Tires | IMPAC Bigpac 55-622 (28″x2.15) TwinSkin or KENDA Kwick Nine (29″x2.0) – ReflectiveLine |
| Disc Rotors | 160 mm front / 160 mm rear |
Electric Components
| Motor | PANASONIC GX Ultimate, 95 Nm, 36 V |
|---|---|
| Battery | KELLYS Re-Charge V10 Li-ion internal removable 725 Wh / capacity 20 Ah, powered by BMZ |
| Display | PANASONIC Bluetooth 5.0 navigation Side Color Display |
Accessories
| Lights | Front: AXA Compactline 35, Rear: TRELOCK Duo Flat |
|---|---|
| Fenders | plastic |
