Build
| Frame | KELLYS E-CARSON R-series – advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / integrated removable battery, 1.5 tapered HT |
|---|---|
| Fork | ROCK SHOX Recon GOLD RL (29″) Boost, 100 mm, DebonAir / Motion Control / Maxle Stealth 15 mm thru axle Travel: 100mm Spring Type: Air |
| Stem | PROMAX a-head adjustable – diam 28.6 mm / bar bore 31.8 mm / length 85 mm |
| Handlebar | KLS Active RiseBar – diam 31.8 mm / rise 18 mm / width 700 mm |
| Saddle | SELLE ROYAL Vivo |
| Seatpost | KLS Active – diam 30.9 mm / length 350 mm Type: Rigid |
| Pedals | plastic |
| Grips | KLS Wave 2Density ergonomic |
Groupset
| Rear Derailleur | SHIMANO Deore XT Linkglide M8130 (direct mount) |
|---|---|
| Crank | MIRANDA Delta (36T) – length 170 mm |
| Shifters | SHIMANO Deore XT Linkglide SL-M8130-R Rapidfire Plus (I-Spec EV) |
| Cassette | SHIMANO Linkglide SC-LG600-11 (11-50T) |
| Chain | SHIMANO Linkglide CN-LG500 (122 links) |
| Brakes | SHIMANO MT410 hydraulic disc Type: Hydraulic Disc |
| Brake Levers | SHIMANO BL-MT4100 |
Wheels
| Rims | KLS Valor 3 Disc 622×30 (32 holes) |
|---|---|
| Spokes | stainless steel black |
| Front Hub | SHIMANO MT400-B / Alivio M4050 Disc Center Lock (32 holes) |
| Rear Hub | SHIMANO MT400-B / Alivio M4050 Disc Center Lock (32 holes) |
| Tires | SCHWALBE Smart Sam Performance 57-622 (29″x2.25) ADDIX, ReflectiveLine |
| Disc Rotors | 180 mm front / 180 mm rear |
Electric Components
| Motor | PANASONIC GX Ultimate, 95 Nm, 36 V |
|---|---|
| Battery | KELLYS Re-Charge V10 Li-ion internal removable 725 Wh / capacity 20 Ah, powered by BMZ |
| Display | PANASONIC Bluetooth 5.0 navigation Side Color Display |
Accessories
| Lights | Front: TRELOCK Veo 50, Rear: TRELOCK Duo Flat |
|---|---|
| Fenders | aluminium |
