Build
| Frame |
KELLYS ESTIMA series – advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / integrated removable battery, 1.5 tapered HT |
|---|---|
| Fork |
FOX AWL (27.5″) Boost, 120 mm, EVOL air / RAIL damper / 15QR thru axle Travel:Â 120mm Spring Type:Â Air |
| Stem |
PROMAX a-head adjustable – diam 28.6 mm / bar bore 31.8 mm / length 85 mm |
| Handlebar |
KLS Active RiseBar – diam 31.8 mm / rise 18 mm / width 700 mm |
| Saddle |
SELLE ROYAL Essenza Relaxed |
| Seatpost |
KS Rage-iS Remote Telescopic – diam 30.9 mm / length 388 mm, travel 125 mm Type:Â Dropper |
| Pedals |
plastic |
| Grips |
KLS Wave 2Density ergonomic |
Groupset
| Rear Derailleur |
SHIMANO Deore XT Linkglide M8130 (direct mount) |
|---|---|
| Crank |
MIRANDA Delta (36T) – length 170 mm |
| Shifters |
SHIMANO Deore XT Linkglide SL-M8130-R Rapidfire Plus (I-Spec EV) |
| Cassette |
SHIMANO Linkglide CS-LG600-11 (11-50T) |
| Chain |
SHIMANO Linkglide CN-LG500 (122 links) |
| Brakes |
SHIMANO MT420 Hydraulic Disc Type:Â Hydraulic Disc |
| Brake Levers |
SHIMANO BL-M4100 |
Wheels
| Rims |
KLS Valor 3 Disc 584×30 (32 holes) |
|---|---|
| Spokes |
stainless steel black |
| Front Hub |
SHIMANO MT400-B Disc Center Lock (32 holes) |
| Rear Hub |
SHIMANO MT400-B Disc Center Lock (32 holes) |
| Tires |
SCHWALBE Johnny Watts Performance 65-584 (27.5″x2.60) RaceGuard, ADDIX, ReflectiveLine |
| Disc Rotors |
180 mm front / 180 mm rear |
Electric Components
| Motor |
PANASONIC GX Ultimate, 95 Nm, 36 V |
|---|---|
| Battery |
KELLYS Re-Charge K1 Li-ion internal removable 820 Wh / capacity 23 Ah, co-developed by Kellys-BMZ |
| Display |
PANASONIC Bluetooth 5.0 navigation Side Color Display |
Accessories
| Lights |
Front: TRELOCK Airflow 100, Rear: TRELOCK Duo Flat |
|---|---|
| Fenders |
plastic |
