Build
| Frame |
KELLYS TAYEN R-series – advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / integrated removable battery, 1.5″ tapered HT, 12×148 mm Boost thru axle |
|---|---|
| Fork |
SR SUNTOUR XCR32-AIR LOR DS (27.5″), 120 mm, air / Speed Lockout / 15 mm thru axle Travel:Â 120mm Spring Type:Â Air |
| Stem |
KLS Alm/En 50 – diam 28.6 mm / bar bore 31.8 mm / lenght 45 mm |
| Handlebar |
KLS Active RiseBar – diam 31.8 mm / rise 18 mm / width 700 mm |
| Saddle |
SELLE ROYAL Vivo |
| Seatpost |
KLS Active – diam 30.9 mm / length 350 mm Type:Â Rigid |
| Pedals |
plastic |
| Grips |
KLS Poison OneLockon |
Groupset
| Rear Derailleur |
SHIMANO Cues U4000 (direct mount) |
|---|---|
| Crank |
MIRANDA Delta (36T) – length 170 mm |
| Shifters |
SHIMANO Cues SL-U4000-9R Rapidfire Plus |
| Cassette |
SHIMANO Linkglide CS-LG400-9 (11-41T) |
| Chain |
SHIMANO Linkglide CN-LG500 (118 links) |
| Brakes |
SHIMANO MT200 Hydraulic Disc Type:Â Hydraulic Disc |
| Brake Levers |
SHIMANO BL-MT200 |
Wheels
| Rims |
KLS Draft 23 Disc 584×23 (32 holes) |
|---|---|
| Spokes |
stainless steel black |
| Front Hub |
SHIMANO TC500-15-B / MT400-B Disc Center Lock (32 holes) |
| Rear Hub |
SHIMANO TC500-15-B / MT400-B Disc Center Lock (32 holes) |
| Tires |
SCHWALBE Smart Sam 57-584 (27.5″x2.25) |
| Disc Rotors |
180 mm front / 180 mm rear |
Electric Components
| Motor |
PANASONIC GX Ultimate, 95 Nm, 36 V |
|---|---|
| Battery |
KELLYS Re-Charge V10 Li-ion internal removable 725 Wh / capacity 20 Ah, powered by BMZ |
| Display |
PANASONIC Bluetooth 5.0 navigation Side Color Display |
