Build
| Frame | KELLYS TAYEN R-series – advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / integrated removable battery, 1.5″ tapered HT, 12×148 mm Boost thru axle |
|---|---|
| Fork | SR SUNTOUR Raidon 34 LOR DS (27.5″) Boost, 120 mm, air / 15 mm thru axle Travel: 120mm Spring Type: Air |
| Stem | KLS Alm/En 50 – diam 28.6 mm / bar bore 31.8 mm / length 45 mm |
| Handlebar | KLS Active RiseBar – diam 31.8 mm / rise 18 mm / width 700 mm |
| Saddle | SELLE ROYAL Vivo |
| Seatpost | KLS Active – diam 30.9 mm / length 350 mm Type: Rigid |
| Pedals | plastic |
| Grips | KLS Poison OneLockon |
Groupset
| Rear Derailleur | SHIMANO Cues U6000 (direct mount) |
|---|---|
| Crank | MIRANDA Delta (36T) – length 170 mm |
| Shifters | SHIMANO Cues SL-U6000-10 Rapidfire Plus |
| Cassette | SHIMANO Linkglide CS-LG300-10 (11-48T) |
| Chain | SHIMANO Linkglide CS-LG500 (118 links) |
| Brakes | SHIMANO MT200 Hydraulic Disc Type: Hydraulic Disc |
| Brake Levers | SHIMANO BL-MT200 |
Wheels
| Rims | KLS Valor 3 Disc 584×30 (32 holes) |
|---|---|
| Spokes | stainless steel black |
| Front Hub | SHIMANO MT400-B Disc Center Lock (15×110 mm / 12×148 mm / 32 holes) |
| Rear Hub | SHIMANO MT400-B Disc Center Lock (15×110 mm / 12×148 mm / 32 holes) |
| Tires | SCHWALBE Nobby Nic Performance 65-584 (27.5″x2.60) ADDIX, folding |
| Disc Rotors | 180 mm front / 180 mm rear |
Electric Components
| Motor | PANASONIC GX Ultimate, 95 Nm, 36 V |
|---|---|
| Battery | KELLYS Re-Charge V10 Li-ion internal removable 725 Wh / capacity 20 Ah, powered by BMZ |
| Display | PANASONIC Bluetooth 5.0 navigation Side Color Display |
