Build
| Frame |
KELLYS TAYEN R-series – advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / integrated removable battery, 1.5 tapered HT, 12×148 mm Boost thru axle |
|---|---|
| Fork |
ROCK SHOX 35 GOLD RL (29) Boost, 120 mm, DebonAir / Motion Control / Maxle Stealth 15 mm thru axle Travel:Â 120mm Spring Type:Â Air |
| Stem |
KLS Alm/En 50 – diam 28.6 mm / bar bore 31.8 mm / lenght 45 mm |
| Handlebar |
KLS Active RiseBar – diam 31.8 mm / rise 18 mm / width 700 mm |
| Saddle |
SELLE ROYAL Vivo |
| Seatpost |
LIMOTEC A1 Remote Telescopic – diam 30.9 mm / length 445 mm, travel 150 mm Type:Â Dropper |
| Pedals |
plastic |
| Grips |
KLS Poison OneLockon |
Groupset
| Rear Derailleur |
SHIMANO Deore XT M8100 (direct mount) |
|---|---|
| Crank |
MIRANDA Delta (36T) – length 170 mm |
| Shifters |
SHIMANO Deore SL-M6100-IR Rapidfire Plus (I-Spec EV) |
| Cassette |
SHIMANO CS-M6100-12 (10-51T) |
| Chain |
SHIMANO CN-M6100 (122 links) |
| Brakes |
SHIMANO Deore MT420 Hydraulic Disc Type:Â Hydraulic Disc |
| Brake Levers |
SHIMANO Deore BL-M4100 |
Wheels
| Rims |
KLS Valor 3 Disc 622×30 (32 holes) |
|---|---|
| Spokes |
stainless steel black |
| Front Hub |
SHIMANO MT400-B / Deore MT410-B Disc Center Lock (15×110 mm / 12×148 mm / 32 holes) |
| Rear Hub |
SHIMANO MT400-B / Deore MT410-B Disc Center Lock (15×110 mm / 12×148 mm / 32 holes) |
| Tires |
SCHWALBE Nobby Nic Performance 60-622 (29×2.40) ADDIX, folding |
| Disc Rotors |
180 mm front / 180 mm rear |
Electric Components
| Motor |
PANASONIC GX Ultimate, 95 Nm, 36 V |
|---|---|
| Battery |
KELLYS Re-Charge K1 Li-ion internal removable 725 Wh / capacity 20 Ah, co-developed by KELLYS-BMZ |
| Display |
PANASONIC color LCD side display |
