Build
| Frame |
KELLYS e-FRAME Allmountain, Uni-Body Integrated Design / Four-bar link, 150 mm rear travel, tapered HT, mullet 29 / 27.5+ wheelset, 12×148 mm Boost thru axle |
|---|---|
| Fork |
ROCK SHOX 35 GOLD RL (29) Boost, 160 mm, DebonAir / Motion Control / Maxle Stealth 15 mm thru axle Travel:Â 160mm Spring Type:Â Air |
| Shock |
ROCK SHOX Deluxe Select R, DebonAir / Trunnion mount (205×65 mm) Travel:Â 150mm |
| Stem |
KLS Alm/En 50 – diam 28.6 mm / bar bore 31.8 mm / length 60 mm |
| Handlebar |
KLS Alm/En 70 RiseBar – diam 31.8 mm / rise 25 mm / width 760 mm |
| Saddle |
fizi:k Taiga, S-alloy rails |
| Seatpost |
KS Rage-i Remote Telescopic – diam 31.6 mm / length 442 mm, travel 150 mm Type:Â Dropper |
| Pedals |
plastic |
| Grips |
KLS Poison OneLockon |
Groupset
| Rear Derailleur |
SHIMANO Deore M5120 (direct mount) |
|---|---|
| Crank |
SHIMANO E8000 (38T) – length 170 mm |
| Shifters |
SHIMANO Deore SL-M4100-R Rapidfire Plus (I-Spec EV) |
| Cassette |
SHIMANO CS-HG4100-10 (11-46T) |
| Chain |
KMC e10T (116 links) |
| Brakes |
SHIMANO Deore MT410 Hydraulic Disc Type:Â Hydraulic Disc |
| Brake Levers |
SHIMANO Deore BL-M4100 |
Wheels
| Rims |
KLS Valor 3 Disc (622×30 front / 584×30 rear / 32 holes) |
|---|---|
| Spokes |
stainless steel black |
| Front Hub |
SHIMANO MT400-B Disc Center Lock (32 holes) |
| Rear Hub |
SHIMANO MT400-B Disc Center Lock (32 holes) |
| Tires |
Front: SCHWALBE Nobby Nic Performance 65-622 (29×2.60) ADDIX, Rear: SCHWALBE Nobby Nic Performance 70-584 (27.5×2.80) ADDIX |
| Disc Rotors |
203 mm front / 203 mm rear |
Electric Components
| Motor |
SHIMANO STEPS E7000, 36 V |
|---|---|
| Battery |
KELLYS Re-Charge Li-ion internal 630 Wh / capacity 17.5 Ah |
| Display |
SHIMANO SC-E5000 cycle computer with assist switch |
