Build
| Frame | KELLYS THEOS R-series – advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / Think Link suspension system, 130 mm rear travel, integrated removable battery, 1.8″ tapered HT, post mount 203 mm, mullet 29″ / 27.5″+ wheelset, 12×148 mm Boost thru axle |
|---|---|
| Fork | ROCK SHOX Zeb Select (29″) Boost, 150 mm, DebonAir+ / Charger RC / Maxle Stealth 15 mm thru axle Travel: 150mm Spring Type: Air |
| Shock | ROCK SHOX Deluxe Select+ RT, DebonAir+ / Open-Threshold (210×55 mm) Travel: 130mm |
| Stem | KLS Alm/En 50 – diam 28.6 mm / bar bore 31.8 mm / length 60 mm |
| Handlebar | KLS Alm/En 70 RiseBar – diam 31.8 mm / rise 25 mm / width 780 mm |
| Saddle | fizi:k Taiga, S-alloy rails |
| Seatpost | LIMOTEC A1 Remote Telescopic – diam 30.9 mm / length 445 mm, travel 150 mm Type: Dropper |
| Pedals | plastic |
| Grips | KLS Poison OneLockon |
Groupset
| Rear Derailleur | SHIMANO Deore XT Linkglide M8130 (direct mount) |
|---|---|
| Crank | MIRANDA Miranda (34T) – length 170 mm |
| Shifters | SHIMANO Deore XT Linkglide SL-M8130-R Rapidfire Plus (I-Spec EV) |
| Cassette | SHIMANO Linkglide CS-LG600-11 (11-50T) |
| Chain | SHIMANO Linkglide CS-LG500 (122 links) |
| Brakes | SHIMANO SLX M7120 Hydraulic Disc Type: Hydraulic Disc |
| Brake Levers | SHIMANO SLX BL-M7100 |
Wheels
| Rims | NOVATEC M30 622×30 front / NOVATEC M35 584×35 Center Lock rear (15×110 mm / 12×148 mm) |
|---|---|
| Tires | Front: SCHWALBE Magic Mary Evo Super Trail 62-622 (29″x2.40) Tubeless Easy, ADDIX Ultra Soft, folding, Rear: SCHWALBE Big Betty Evo Super Trail 65-584 (27.5″x2.60) Tubeless Easy, ADDIX Soft, folding |
| Disc Rotors | SHIMANO RT30 203 mm front / EM300 203 mm rear |
Electric Components
| Motor | PANASONIC GX Ultimate, 95 Nm, 36 V |
|---|---|
| Battery | KELLYS Re-Charge K1 Li-ion internal removable 725 Wh / capacity 20 Ah, co-developed by Kellys-BMZ |
| Display | PANASONIC Bluetooth 5.0 navigation Side Color Display |
