Build
| Frame | KELLYS TYGON R-series – advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / integrated removable battery, 1.5″ tapered HT, 12×148 mm Boost thru axle |
|---|---|
| Fork | SR SUNTOUR XCM 32 DS (29″) Boost, 120 mm, coil spring / 15 mm thru axle Travel: 120mm Spring Type: Coil |
| Stem | KLS Alm/En 50 – diam 28.6 mm / bar bore 31.8 mm / length 60 mm |
| Handlebar | KLS Active RiseBar – diam 31.8 mm / rise 18 mm / width 720 mm |
| Saddle | SELLE ROYAL Vivo |
| Seatpost | KLS Active – diam 30.9 mm / length 350 mm Type: Rigid |
| Pedals | plastic |
| Grips | KLS Poison OneLockon |
Groupset
| Rear Derailleur | SHIMANO Altus M2000 (direct mount) |
|---|---|
| Crank | MIRANDA Delta (36T) – length 170 mm |
| Shifters | SHIMANO Altus SL-M2000 Rapidfire Plus |
| Cassette | SHIMANO CS-HG400-9 (11-36T) |
| Chain | KMC e9S (118 links) |
| Brakes | SHIMANO MT200 Hydraulic Disc Type: Hydraulic Disc |
| Brake Levers | SHIMANO BL-MT200 |
Wheels
| Rims | KLS Draft Disc 622×21 (32 holes) |
|---|---|
| Spokes | stainless steel black |
| Front Hub | SHIMANO MT400-B Disc Center Lock (32 holes) |
| Rear Hub | SHIMANO MT400-B Disc Center Lock (32 holes) |
| Tires | SCHWALBE Rapid Rob 57-622 (29″x2.25) K-Guard |
| Disc Rotors | 180 mm front / 180 mm rear |
Electric Components
| Motor | PANASONIC GX Ultimate, 95 Nm, 36 V |
|---|---|
| Battery | KELLYS Re-Charge K1 Li-ion internal removable 725 Wh / capacity 20 Ah, co-developed by Kellys-BMZ |
| Display | PANASONIC Bluetooth 5.0 navigation Side Color Display |
