Marin Alpine Trail 1 Bike 2025 Overview
Build
| Frame | All New Series 4 6061 Aluminum, 29 Wheels, 160mm Travel MultiTrac LT Suspension Platform, Integrated Downtube Storage, Adjustable Headset & CS Length/BB Height, Full Internal Cable Routing, Chainstay Mounted Post Mount Disc Brake, 148x12mm Boost Thru- Axle, 73mm Threaded BB w/ ISCG05 Tabs BB Standard: BSA, 73mm, Threaded Color: Gloss Brown / Blue/light Blue |
|---|---|
| Fork | Fox 36 Rhythm, 170mm Travel, 29″, Grip Damper, 110×10 Kabolt, 44mm Offset Travel: 170mm Spring Type: Air |
| Bottom Bracket | FSA MegaExo 73mm BSA |
| Headset | FSA Custom, Adjustable HTA Design |
| Stem | Marin 3D Forged Alloy, 35mm |
| Handlebar | Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5 Up, 9 Back |
| Saddle | Marin Speed Concept |
| Seatpost | TranzX, YSP39 1x Remote, 34.9 Seatpost Diameter, Travel S = 150mm, M/L = 170mm, XL = 200mm Type: Dropper |
| Pedals | – |
| Grips | Marin Grizzly Lock-On |
Groupset
| Rear Derailleur | Shimano Deore, 12-Speed, SGS |
|---|---|
| Front Derailleur | – |
| Crank | FSA Comet Heavy Duty, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing |
| Shifters | Shimano Deore, 12-Speed, SL-6100-IR |
| Cassette | Shimano, Deore M6100 12-Speed, 10-51T |
| Chain | KMC X-12 Silver and Black |
| Brakes | TRP Slate EVO, 4-Piston Hydraulic Disc, Resin Pads, 203mm Rotor Type: Hydraulic Disc |
| Brake Levers | TRP Slate EVO Hydraulic, I-Spec EV Compatible |
