Build
| Frame |
Series 4 Alloy Frame, 150mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor Color:Â Gloss Blue / Black |
|---|---|
| Fork |
X-Fusion Trace 36 RC, 160mm Travel, 29″, 110x15mm Bolt-On Axle, 44mm Offset Travel:Â 160mm Spring Type:Â Air |
| Headset |
FSA No 57E, Sealed Cartridge Bearings, 1 1/8″ x 1 1/2 |
| Stem |
Marin 3D Forged Alloy, 35mm |
| Handlebar |
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5 Up, 9 Back |
| Saddle |
Marin eMTB Saddle |
| Seatpost |
TranzX, YSP18JL, 1x Remote, Size S 150mm Travel, All Other Sizes 170mm Travel, 30.9mm Type:Â Dropper |
| Pedals |
Marin MTB Plastic |
| Grips |
Marin Grizzly Lock On |
Groupset
| Rear Derailleur |
Shimano CUES 10-Speed |
|---|---|
| Crank |
Shimano EM600, 160mm Length, 38t Chainring |
| Shifters |
Shimano Deore, 10-Speed, I-Spec EV |
| Cassette |
Shimano Deore 10-speed 11-46T |
| Chain |
KMC X-10E, Silver |
| Brakes |
TRP Slate EVO 4-Piston Hydraulic, 203mm Rotor, 2.3mm Thick Type:Â Hydraulic Disc |
| Brake Levers |
TRP Slate EVO |
Wheels
| Rims |
Front: Marin Aluminum Double Wall, 29″ Diameter, 32mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible; Rear: Marin Aluminum Double Wall, 27.5″ Diameter, 38mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible |
|---|---|
| Front Hub |
Shimano FH-TC500, 110x15mm, Centerlock, 32H |
| Rear Hub |
Shimano HB-TC500, 148x12mm, Centerlock, Standard Freehub Body |
| Tires |
Front: Vee Tire Co. Attack HPL, 29×2.5″, Top 40 Tubeless Compatible Rear: Vee Tire Co. Crown Gem, 27.5×2.8, TACKEE Compound, Tubeless Compatible |
Electric Components
| Motor |
Shimano Steps EP6 Drive Unit, 250W, 85Nm, 20MPH Top Assisted Speed |
|---|---|
| Battery |
BT-EN805-L, Internal 504Wh Recycling Program:Â Â Call2Recycle |
| Display |
Shimano SC-E600 |
