Marin Alpine Trail E1 Bike 2025 Overview
Build
| Frame |
Series 4 Alloy Frame, 150mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor Color:Â Gloss Green / Black |
|---|---|
| Fork |
X-Fusion Trace 36 RC, 160mm Travel, 29″, 110x15mm Bolt-On Axle, 44mm Offset Travel:Â 160mm Spring Type:Â Air |
| Shock |
RockShock Super Deluxe Coil R, Rebound Adjustment, 205x65mm, 25mmxM8 Lower Hardware, S/M Spring Rate = 300lb, L/XL Spring Rate = 400lb Travel:Â 150mm Spring Type:Â Coil |
| Headset |
FSA No 57E, Sealed Cartridge Bearings, 1 1/8″ x 1 1/2 |
| Stem |
Marin 3D Forged Alloy, 35mm |
| Handlebar |
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5 Up, 9 Back |
| Saddle |
Marin eMTB Saddle |
| Seatpost |
TranzX, YSP23JL, 1x Remote, Size S 150mm Travel, Size M and L 170mm Travel, Size XL 200mm Travel, 30.9mm Type:Â Dropper |
| Pedals |
Marin MTB Plastic |
| Grips |
Marin Grizzly Lock On |
Groupset
| Rear Derailleur |
Shimano Deore, Direct Attachment, 11-Speed, SGS |
|---|---|
| Crank |
Shimano EM600, 160mm Length, 38t Chainring |
| Shifters |
Shimano Deore, 11-Speed, I-Spec EV |
| Cassette |
SunRace 11-Speed, 11-51T |
| Chain |
KMC X-10E, Silver |
| Brakes |
Shimano MT420, 4-Piston Hydraulic Disc, Metallic Pads, 203mm Rotor Type:Â Hydraulic Disc |
| Brake Levers |
Shimano SLX Levers, I-Spec EV |
