Build
| Frame | All New, Series 4 Alloy, 160mm MultiTrac Suspension LT, Adjustable Headset & CS Length/Height, Integrated Battery/Charging Port, 148mm Rear Thru-Axle Color: Charcoal / Black |
|---|---|
| Fork | Fox 38 Performance Elite, 170mm Travel, 29″, 110x15mm Boost Kabolt Thru-Axle, 44mm Offset, Integrated Fox Fender Travel: 170mm Spring Type: Air |
| Headset | FSA Custom Headset, Adjustable HTA Design |
| Stem | Marin CNC, 35mm Length, 35mm Bar Bore |
| Handlebar | Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back |
| Saddle | Marin Speed Concept |
| Seatpost | TranzX, YSP39 1x Remote, 34.9 Seatpost Diameter, Travel S = 150mm, M/L = 170mm, XL = 200mm Type: Dropper |
| Pedals | – |
| Grips | Marin Grizzly Lock On |
Groupset
| Rear Derailleur | Shimano XT 12-Speed, SGS |
|---|---|
| Front Derailleur | – |
| Crank | e*thirteen e*spec Plus Cranks, 160mm Length |
| Shifters | Shimano SLX 12-Speed, I-Spec EV |
| Cassette | Shimano SLX M7100 Cassette, 12-Speed, 10-51T |
| Chain | KMC E12S, E-Bike Specific Chain |
| Brakes | TRP DH-R EVO 4-Piston Hydraulic Disc, 203mm, 2.3mm Thick Type: Hydraulic Disc |
| Brake Levers | TRP DH-R EVO Hydraulic |
Wheels
| Rims | Front: Marin Aluminum Double Wall, 29″ Diameter, 32mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible; Rear: Marin Aluminum Double Wall, 27.5″ Diameter, 32mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible |
|---|---|
| Spokes | 14g Black Stainless Steel |
| Front Hub | Shimano FH-TC500, 110x15mm, Centerlock, 32H |
| Rear Hub | Shimano HB-TC500, 148x12mm, Centerlock, Standard Freehub Body |
| Tires | Vee Tire Co Attack HPL, E-Control Compound, Front 29×2.5″, Rear 27.5×2.5″ |
Electric Components
| Motor | Bosch Performance Line CX, 85Nm, 20MPH (US, NZ)/25 km/h (Rest of World) Top Assisted Speed |
|---|---|
| Battery | Bosch PowerTube 750 Wh Recycling Program: Call2Recycle |
| Display | Bosch BRC3100 Systems Controller |
